公司简介：

Faraday Photonics公司老板Beth Percevault是一位女性，设计和制造满足专门的独特要求光学隔离器，除了标准产品线，还提供各种波长和功率水平以及多种应用光学隔离器。Beth是美国罗切斯特大学的毕业生，背景是光学研究(OFR)的光学隔离器，是包括与广泛的自由空间和光纤隔离器在既定的产品线和开发第一个商业上可用的二氧化碳隔离器等光学隔离器的先驱。其团队是Lasermetrics分部、Fast Pulse和欧洲航天局工作，有设计、建造和满足光学隔离器在卫星上发射的空间资格。

产品列表：

Standard Isolators

1064  1550  1645  1940  2000  2050  2090  2200  2350  2500  2700  2800  2900  2940  3100  3250  3390

Series 2110

Optical Isolators and Faraday Rotators

IR 1.55-3.4 MICRONS

The 1.55-3.4 µm range requires several types of Faraday rotator materials and polarizers for maximum isolation and transmission.

In addition to our listed wavelengths, there are many isolator design customization options to maximize performance for your specific laser wavelength. Please contact us. Our designs will be configured for your laser wavelength.

ISO-5-1645-CP, Optical Isolator

         Wavelength: 1645 nm, Bandwidth 1530-1680 nm
         Aperture: 4.5 mm
         Power: 15 W
         Isolation: 35-40 dB
         Transmission: 88-90%
         Calcite Polarizers

ISO-5-1940-MP, Optical Isolator

ISO-5-IR-MP DRAWING

Wavelength: 1940 nm, Bandwidth: 1850-2000 nm
Aperture: 4.5 mm
Power: 10 W
Isolation: 35-40 dB
Transmission: 86-90%
Crystal Polarizers

ISO-3-2000-MP, Optical Isolator

IS0-5-IR-MP (G2) DRAWING

Wavelength: 2000 nm, Bandwidth: 1910-2100 nm
Aperture: 3 mm
Power: 5 W
Isolation: 34-40 dB
Transmission: 88-92%
Crystal Polarizers

ISO-5-2000-MP, Optical Isolator

ISO-5-IR-MP (G2) DRAWING

Wavelength: 2000 nm, Bandwidth: 1940-2060 nm
Aperture: 4.5 mm
Power: 20 W
Isolation: 34-40 dB
Transmission: 88-90%
Crystal Polarizers

ISO-5-2050-MP, Optical Isolator

ISO-5-IR-MP (G2) DRAWING

Wavelength: 2050 nm, Bandwidth: 2000-2100 nm
Aperture: 4.5 mm
Power: 20 W
Isolation: 34-40 dB
Transmission: 88-90%
Crystal Polarizers

FR-5-2050, Faraday Rotator

Wavelength: 2050 nm
Aperture: 4.5 mm
Power: 20 W
Faraday Rotation @ 2050 nm: 45 deg
Transmission: 98%

FR-8-2050, Faraday Rotator

       Wavelength: 2050 nm
       Aperture: 8mm
       Power: 20 W
       Faraday Rotation @ 2050 nm: 45 deg
       Transmission: 98%

ISO-5-2090-MP, Optical Isolator

ISO-5-IR-MP (G2) DRAWING

Wavelength: 2090 nm, Bandwidth: 2030-2130 nm
Aperture: 4.5 mm
Power: 20 W
Isolation: 34-40 dB
Transmission: 88-90%
Crystal Polarizers

ISO-5-2350-AP, Optical Isolator

ISO-5-IR-AP DRAWING

Wavelength: 2350 nm, Bandwidth: 2250-2450 nm
Aperture: 4.5 mm
Power: 200 mW
Isolation: 30-37 dB
Transmission: 86-90%
Absorptive Polarizers

ISO-5-2350-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 2350 nm, Bandwidth: 2250-2450 nm
Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: ~85%
Crystal Polarizers

FR-5-2350, Faraday Rotator

Wavelength: 2350 nm
Aperture: 4.5 mm
Faraday Rotation @ 2350 nm: 45 deg
Power: 10 W
Transmission: 95-97%

ISO-5-2500-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 2500 nm, Bandwidth: 2400-2600nm
Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: ~83%
Crystal Polarizers

ISO-5-2700-AP, Optical Isolator

ISO-5-IR-AP DRAWING

Wavelength: 2700 nm, Bandwidth: 2600-2800nm
Aperture: 4.5 mm
Power: 200 mW
Isolation: 35-40 dB
Transmission: 85-88%
Absorptive Polarizers

ISO-5-2700-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 2700 nm, Bandwidth: 2600-2800nm
Aperture: 4.5 mm
Power: 5 W
Isolation: 30-35 dB
Transmission: 80%
Crystal Polarizers

ISO-5-2800-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 2800 nm
Bandwidth: 2750-2870 nm  (Small absorption bands of  ~10% may exist in the 2835 nm region)   Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: 80%
Crystal Polarizers

ISO-5-IR (G2) DRAWING

ISO-5-2900-MP, Optical Isolator

Wavelength: 2900 nm                              Bandwidth: 2850-3000 nm (Small absorption bands of  ~10% may exist in the 2835 nm region)
Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: 80%
Crystal Polarizers

ISO-5-2940-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 2940 nm, Bandwidth: 2900-3000nm
Aperture: 4.5 mm
Power: >5 W
Isolation: 28-35 dB
Transmission: 80%
Crystal Polarizers

ISO-5-3000-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 3000 nm, Bandwidth: 2950-3100 nm
Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: 80%
Crystal Polarizers

ISO-5-3200-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 3200 nm, Bandwidth: 3100-3250 nm
Aperture: 4.5 mm
Power: 5 W
Isolation: 28-35 dB
Transmission: 82%
Crystal Polarizers

ISO-3-3390-MP, Optical Isolator

ISO-5-IR (G2) DRAWING

Wavelength: 3390 nm, Bandwidth: 3300-3420 nm
Aperture: 2.7 mm
Power: 1 W
Isolation: 28-35 dB
Transmission: ~84%
Crystal Polarizers
