公司简介

德国LAYERTEC公司创建于1990年. 凭借多年在光学镜片的设计开发和生产经验,已成为全球知名的光学镜片厂商,LAYERTEC的镜片品质非常出众,广泛赢得客户的赞誉。光学镜片应用波长范围从157-2940nm,包括了科研以及工业上主流的激光器的应用,材质有YAG,Sapphire,CaF2,IR-fused silica,Fused Silica,BK7,尺寸大部份为0.5英寸-2英寸。


LAYERTEC主要产品包括:

各种飞秒激光器以及研究应用的宽带镜,啁啾镜(负色散镜),GT干涉镜等。

低色散镜:一般应于于超快激光器的腔镜,输出耦合镜,分光镜,具有大的光谱带宽和精确的色散控制。低色散意味着IGVDI<20fs,标准带宽是200nm左右(中心波长在800nm左右),更宽的可以达到300nm。另外,金属镀膜镜也具有宽带宽低色散的特性。

高功率飞秒光学元件:高激光损伤阀值,对于150fs脉冲激光来说,损伤阈值可以超过0.75J/cm2。

负色散镜:LAYTERTEC的负色散镜具有非常高的反射率(R=99.8% >99.9%),因此可以提高反射次数来达到补偿效果,反射次数可达1020次。

Gires-Tournios干涉镜:GT干涉镜可以提供对大的负色散和相对小的反射带宽。


产品列表

Nanosecond Laser Optics



Picosecond Laser Optics




Femtosecond Laser Optics

cw and ns Laser Optics

Low Loss Laser Optics


Multipurpose Broadband Mirrors

Metallic Mirrors

Filters for Laser Applications

Uncoated Optics


技术能力

Substrates


Coatings


Quality Control


Components for Common Laser Types


Components for Femtosecond Lasers


Catalog



产品链接

纳秒激光反射镜

HR(0°,157nm)>=92%
HR(0°,193nm)>96%
HR(9°-12°,193nm)>96%
HRr(0°,260nm)>99.5%
HRr(0°,266nm)>99.5%
HR(0°,355nm)>99.9%
HR(0°,355nm)>99.85%
HRs,p(8.5°, 355nm)>99.75% + Rs,p(8.5°, 532nm)<0.5% + Rs,p(8.5°, 1064nm)<5% (high power)
HRs,p(0-20°, 355nm)>99% + HRs,p(0-20°, 532nm)>99% + Rs,p(0-20°, 1064nm)<1%
HR (0°, 515-532nm) >99,9% + R (0° , 1030-1064nm) <1%
HR(0-10°, 532nm)>99.8% + R(0-10°, 1064nm)<1% (High Power)
HR(0-10°,532nm)>99.9% + R(0-10°,1064nm)<0.5% (high power)
HR(0°, 532nm)>99.95% + R(0°, 1064nm)<0.25%, T(0°, 532nm)~0.015%
HRs,p(5-15°, 532nm)>99.9% + Rs,p(5-15°, 1064nm)<1% (high power)
HR(0° + 18°, 655-755nm)>99.9% + R(0° + 18°, 532nm)<2%, |GDD-R(0° + 18°, 655-755nm)|<40fs2
HR(0°,1010-1060nm)>99.9%
HR(0°, 1020-1070nm)>99.9% (High Power)
HR(0°,1030nm)>99.98% (High Power)
HR(0-10°,1030nm)>99.99% (High Power)
HR(0-10°,1030nm)>99.98% + R(0-10°,630-650nm)>50% (high ns-laser power)
HRr(25°-29°,157nm)>92%
HRr(30°,193nm)>96%
HRs(33°,1030nm)>99.98% (High Power ns-laser pulses)
HRr(45°,157nm)>89%
HR(45°,162nm)>90%
HRr(45°,193nm)>95%
HRs(45°,213nm)>97% + Rp(45°,266nm)<2% + Rs(45°,532nm)<10% + Rp(45°,1064nm)<2%
HRr(45°, 248nm)>98% (fluoridic)
HRr(45°,248nm)>99%
HRr(45°,248nm)>99% + Rr(45°,355+848nm)<10%
HRs(45°,266nm)>99.5% + Rp(45°,532+1064nm)<2% + Rs(45°,532+1064nm)<10%
HRr(45°, 308nm)>99.5%
HRr(45°, 308nm)>99.8%
HRs(45°,343nm)>99.9% + Rp(45°,515nm)<0.2% + Rs(45°,1030nm)<0.2%
HRr(45°,351nm)>99.5%
HRr(45°, 355nm)>99.5%
HRr(45°, 355nm + 532nm)>99.5%
TFP(45°,355nm) Rs>99.5% Rp<2%
HRp(45°, 355nm)>99.8% + Rs(45°, 532nm)<1% + Rp(45°, 1064nm)<1%
HRs,p(45°, 532nm)>99.8% + Rs,p(45°, 1064nm)<2% (high power)
HRs,p(45°,1030nm)>99.96% (Zero Phase Shift)
HRr(45°,1030nm)>99.98% (High Power)
HRs(45°, 1030-1064nm)>99.9% (High Power)
HRr(45°, 1064nm)>99.9%
HRr(45°, 1064nm + 532nm)>99.8% + HRr(45°,355nm)>99.4%
HRr(45°,1064nm)>99.9% + Rr(45°,532nm)<10%
HRr(45°,1064nm)>99.9%+HTr(45°, 532+808nm)>90%
HRs(22.5°,343nm)>99.8% + Rp(22.5°,515nm)<1% + Rs(22.5°,1030nm)<1%
TFP(56°, 355nm) Rs>99.5% Rp<2%
TFP(56°(±3°)*, 532nm) Rs>99.8% Rp<2%, (±3°)* angle adjustment
PR(0°, 650-720nm)=80±5% + R(0°, 740-950nm)<10% (analogous F0305017)
PRr(45°,193nm)=30+/-3%
PRr(45°,248nm)=50±3%
PRs,p(45°,532nm)=50±5%, |Rs-Rp|<5%
PRp(45°, 1030-1064nm)=30.0±2%
PRs(45°,1047-1064nm)=95.00±0.75%
VAr(0-45°,157nm) T=80-10%
VAr(0-45°,193nm) T=88-2%
AR(0°,193nm)<0.25%
AR(0°,248nm)<0.25%
AR(0°,355nm)<0.25%
AR(0°, 808+1064nm)<0.2%
AR(0°,940-1060nm)<0.2%
AR(0°,1010-1060nm)<0.25%
AR(0°,1030nm)<0.2%
AR(0°,1030-1064nm)<0.15%
AR(0°,1030-1080nm)<0.25%
ARr(45°,266nm)<0.6%



皮秒激光反射镜

HR(0°,343nm)>99.7% + R(0°,515+1030nm)<1% (ps-pulses)
HR(0°, 515nm)>99.9% (high power)
HR(0°,532nm)>99.9% (High Power)
HR(0°,750-850nm)>99.9% (high power for ps-pulses)
HR(0°,970-1090nm)>99.9% (High Power for ps-Pulses)
HRr(0-20°,970-1090nm)>99.95% (high power)
HR(0°, 980-1090nm)>99.98% (High Power für ps-Pulse)
HR(0°,990-1070nm)>99.98% (High Power für ps-Pulse)
HR(0-10°, 1030±30nm)>99.98% (High Power ps-Pulse)
HR(0°,1000-1100nm)>99.98% (High Power für ps-Pulse)
HR(0°,1030nm)>99.98% (High Power)
HR(0°,1030±30nm)>99.98% (High Power for ps-Pulses)
HRr(0-20°,970-1090nm)>99.95% (high power for ps-pulses)
HR(0°,1030-1064nm)>99.9% (High Power)
HR(0°,1064nm)>99.98% (High Power für ps-Pulse)
HRr(22.5°,1010-1070nm)>99.9% (High Power)
Ag + Multilayer, HRr(0-45°, 1020-1040nm)>99.9%
HRr(45°,213nm)>95% (HRs(45°,208-218nm)>97%, HRp(45°,213nm)>93%) (fluoridisch)
HRs(45°,343nm)>99.9% + HRp(45°,343nm)>99.7%
HRp(45°, 355nm)>99.0% + Rs(45°, 532nm)<3% + Rp(45°, 1064nm)<2%
HRp(45°, 355nm)>99.5% + Rs(45°, 532nm)<5% + Rp(45°, 1064nm)<5%
HRr(45°, 515nm)>99.9% (High Power for ps-pulses), T>0.05%
HRs,p(45°,515nm)>99.9% (High Power für ps)
HRs,p(45°,515nm)>99.9% + Rs,p(45°,1030nm)<2%
HRs(45°,515nm)>99.95% + Rp(45°,1030nm)<1% (high power)
HRr(45°,532nm)>99.9% (High Power for ps)
HRr(45°,1030±40nm)>99.9% (High Power for ps-Pulses)
HRr(45°, 1030±40nm)>99.9% (High Power für ps-Pulse), T>0.05% with HRr~99.95% => |Rs-Rp|~0.1%
HRr(45°,990-1070nm)>99.98% (High Power für ps-Pulse)
HRr(45°,1030±40nm)>99.9% + PRr(633-655nm)>80% (High Power für ps-Pulse)
HRr(45°, 1030nm)>99.9% (High Power für ps-Pulse), T>0.05%
HRr(45°, 1030nm)>99.98% (High Power for ps-pulses)
HRr(45°, 1030nm + 515nm)>99.9% (high power)
TFP(45°, 1030nm) Rs>99.9% Rp<2%
TFP(55°, 1030nm), Rs>99.9%, Rp<1%
PR(0°,1030nm)=75±2%
PR(0°,1030nm)=77±2%
PR(0°,1030nm)=79±2%
PR(0°,1030nm)=81±2%
PR(0°,1030nm)=83±2%
PR(0°,1030nm)=85±2%
PR(0°,1030nm)=87±2%



飞秒激光反射镜

HR(0°,158.5nm)>92% + R(0°,266+800nm)<10%
HR(0°,200nm)>96% (fluoridic)
HR(0°, 220nm)~85% + R(0°, 350-800nm)<10%, band width ~35nm with R~80...90%, |GDD-R(0°, 220)| <20fs2,
HR(0°, 240-330±3nm)>95% + R(0°, 600-920nm)<5%, GDD opt.
HR(0°, 250-400±5nm)>95.0%, GDD( 0°, 265-385nm)~ -10±10fs2, (GDD-oszillation compensated)
HR(0°,267nm)>99% + HR(0°,400nm)>99.3% + HR(0°,800nm)>99.7%, GDD-optimiert
HR(0°,267nm)>99.5% + R(0°,400+800nm)<5%, GVD<20fs2
HR(0°, 315-450±5nm)>99.8%, GDD(330-440nm)~ -25±10fs2, (GDD-oszillation compensated)
HR(0°, 310-460±5nm)>99.8%, GVD(350-470nm)~-30....+20fs2, (GVD-Oscillation compensated)
HR(0°, 310-480nm)>99.7%, GDD(340-490nm)~ -25±50fs2
HR(0°,340-390nm)>99.8%
HR(0°,340-450nm)>99.8%, GVD(350-450nm±10nm)~ -25±20fs2
HR(0°,340-460nm)>99.8%,|GDD(R,0°,340-460nm)|<40fs2
HR(0°, 340-540nm)>99.0% + HR(0°, 665-1070nm)>99.7%, GD opt.
HR(0°, 360-410nm)>99.9%, GVD<20fs2
HR(0°,360-435nm±5nm)>99.9% + R(0°,700-950nm)<2%, GVD<20fs2
1.Mirror:HR(0-8°,360-480nm)>99.5%, 2.Mirror:+10nm, GVD(360-480nm)~-15±15fs2, (GVD-Oscillation compensated)
HR(0°,370-425nm)>99.8%, |GDD|<20fs2
HR(0°, 370-430nm)>99.8%, |GVD|<20fs2
HR(0°, 370-430±5nm)>99.8% + R(0°, 500-1000nm)<2%, |GDD|<20fs2
HR(0°,370-430nm±5nm)>99.9% + R(0°,690-880nm)<2%, |GDD|<20fs2
HR(0°,380-420nm)>99.8%, |GDD|<20fs2
HR(0°,380-440nm±5nm)>99.9% + R(0°,700-900nm)<2%, GVD<20fs2
HR(0°,390-440nm)>99.9%, GVD<20fs2
HR(0°, 390-440+/-4nm)>99.96%, T~0.005...0.03%, Low Loss
HR(0°, 400+800nm)>99.8%
HR(0°, 409nm)>99.98%, T~0.002%, Low Loss
HR(0°,410-470nm)>99.9%, GDD<20fs2
HR(0°, 420-810±6nm)>99.7..99.8%, GVD(470-810nm)~ -40fs2±20fs2 , (GVD-Oszillation compensated)
HR(0°, 440-660nm)>99.85%, GDD-R(0°, 480-660nm)~ -30....-15fs2 (GDD - oscillation compensated and TOD optimized)
HR(0°, 440-720nm)>99.85%, |GDD-R(0°, 440-720nm)|<150fs2
HR(0°, 480-640nm)>99.85%, GDD-R(0°, 480-630nm)~ -70....-40±30fs2 (GDD - oscillation compensated and TOD optimized)
HR(0-15°, 480-960nm)>99.6..99.8%, GVD(510-920nm)~ -40fs2±20fs2 , (GVD-Oszillation kompensiert)
PR(0°,490-750nm)=86±2%, GDD optimised
HR(0-10°,500-650nm)>99.9%
1.mirror:HR(0°,500-950±10nm)>99.6%, 2.mirror:-20nm, GDD(500-930nm)~ -40±20fs2, (GDD-oscillation compensated)
HR(0°, 510-520nm)>99.9% + PR(0°, 1020-1040nm)=70(±3)%, |GDD-R(0°, 510-520nm + 1020-1040nm)|<100fs2
HR(0°, 510-520nm)>99.9% + PR(0°, 1020-1040nm)=80(±3)%, |GDD-R(0°, 510-520nm + 1020-1040nm)|<100fs2
HR(0°, 510-520nm)>99.9% + PR(0°, 1020-1040nm)=90(±2)%, |GDD-R(0°, 510-520nm + 1020-1040nm)|<100fs2
HR(0°, 510-520nm)>99.9% + PR(0°, 1020-1040nm)=95(±1)%, |GDD-R(0°, 510-520nm + 1020-1040nm)|<100fs2
HR(0°,515+1030nm)>99.8% + R(0°,808nm)<5%
HR(0°, 532nm)>99.9%
HR(0°, 540-1040±8nm)>99.7%, GVD(570-1040nm)~ -40±20fs2, (GVD-oszillation compensated)
HR(7°, 500-1000nm)>99.4%, GDD(R,7°,500 -1000nm) designed to compensate 1,5mm FS per double bounce
HR(0°, 560-1000nm)>99.9%, GVD(620-980nm)~-40fs2±15fs2 , (GVD-oszillation compensated)
HR(0°, 570-820nm)>99.85%, GDD-R(0°, 570-820nm)~ -35....-15fs2 (GDD - oscillation compensated and TOD optimized)
HR(0°, 570-840±5nm)>99.8%, GD optimized
HR(0°, 570-1020nm)>99.7%, GDD osc. comp. (0°, 680-980nm)-80fs2...+50fs2, TODopt.
HR(0°, 570-1030±8nm)>99.8%, GVD(0°, 600-1020nm)~ -50fs2±20fs2 , (GVD-Oszillation kompensiert)
1.Mirror:HR(0°, 580-980±10nm)>=99.9%, 2.Mirror:+20nm, GVD(650-1000nm)~ -50±20fs2, (GVD-Oscillation compensated)
HR(0°, 580-1020±10nm)>99.8%, GVD-oscillation(700-1000nm)~-100...0fs2
HR(0°, 580-1030±8nm)>99.9%, GVD(650-1000nm)~ -50fs2±20fs2 , (GVD-oszillation compensated)
HR(0°, 580-1060±8nm)>99.8%, GDD - oscillation~-120...+40fs2
HR(0°, 600-700nm±6nm)>99.9%, GVD<20fs2
both mirrors: HR(0°, 600-900nm)>99.8%, GVD (600-900nm)~ -45fs2±20fs2, (GVD-Oscillation compensated, see data sheet)
HR(0°, 600-930nm)>99.9%, GVD(700-950nm)~ -65±20fs2 (GVD-Oszillation compensated)
HR(0°, 600-980nm)>99.9%, GVD(700-880nm)~-100fs2...+40fs2
HR(0°, 610-1030nm±10nm)>99.8%
HR(0°, 620-720nm±5nm)>99.9%
HR(0°, 620-900±8nm)>99.9%, GVD(700-900nm)~ -65±20fs2(GVD oscillation compensated)
HR(0-12°, 620-1000±7nm)>99.8%, GVD(680-900nm)~-60±20fs2
HR(0°, 620-1000nm)>99.85%, GDD(0°, 700-1000nm)~ -50±20fs2, GDD - osz. compensated
HR(0°, 620-1050nm)>=99.9% + R(0°, 490-540nm)<5%, GDD(680-1020nm)~ -50+/-20fs2, (GDD-oszillation compensated)
HR(0°,620-1080nm)>99.9% + R(0°,488-532nm)<5%
HR(0°, 620-1120±10nm)>99.9%, GD optimized
HR(0°, 630-980nm)>99.7% + R(0°, 515-545nm)<10%, GDD(700-1020nm)~ -70+/-30fs2, (GDD-oszillation compensated)
HR(0°, 630-1100±8nm)>99.8% + R(0°, 480-540nm)<10%
HR(0°, 630-1140+/-10nm)>99.85%, GVD~-200fs2....100fs2
HR(0°, 630-1200nm)>99.8%, |GDD-R(0°, 650-1150nm)|<400fs2
HR(0°,640-1000nm)>99.8% + R(0°,(510-545)±5nm)<15%, GDD(720-1000nm)~ -70±30fs2, (GDD-oscillation compensated)
HR(0°, 630-1000nm)>99.8% + R(0°, 510-550nm)<10%, GVD(720-1020nm)~ -70±30fs2
HR(0°, 640-1080+/-8nm)>99.9% + R(0°, 490-540+/-5nm)<5%, GVD~ -200...+100fs2 (GVD optimized for OPO-application)
HR(0°, 650-860±7nm)>99.9%, GVD(770-795nm)~-550±75fs2
HR(0°, 650-900±5nm)>99.9%, GVD(700-900nm)~ -100±30fs2 , (GVD-oszillation compensated)
HR(0°, 650-900±8nm)>99.9%, GVD~-150fs2....0fs2, with smoothed GD
HR(0°, 650-1100nm)>99.8%, GD optimized
HR(0°, 650-1070±8nm)>99.9%, GVD(740-980nm)=-70±30fs2
HR(0°,650-1100nm)>99.8% + R(0°,488-532nm)<5%
HR(0°,660-980nm±10nm)>99.7% + R(0°,500-550nm)<5%, GVD~-50±20fs2(730-1000±10nm)
HR(0°, 660-1050nm)>99.9%, High Power optimized (780-850nm)
booth mirrors HR(0°, 660-1060nm)>99.8%, GDD(730-970nm)= -70±20fs2, (GDD-Oszillation compensated)
HR(0°, 660-1100±9nm)>99.8%, GVD(740-1010nm)=-70±20fs2
HR(0°,660-1130nm±10nm)>99.9%, GVD(780-1010nm)~ -120fs2...+40fs2
HR(0°, 660-1130+/-8nm)>99.9% + R(0°, 510-550+/-5nm)<5%, GVD~ -200...0fs2 (GVD optimized for OPO-application)
HR(0°,660-1150nm)>99.9% + R(0°,480-560nm)<5%
HR(0°,670-1000nm)>99.8%, GVD(700-970nm)=-60±20fs2
HR(0-5°, 670-1020nm)>99.8%, GDD Osz. compens. (0-5°, 730-850nm) ~-500...+750±100fs2, TOD opt.
HR(0-5°, 670-1040nm)>99.8%, GDD Osz. compens. (0-5°, 770-990nm) ~-120±30fs2
HR(0°, 680-890±7nm)>99.8%, GVD (0°, 720-880nm)~+100±30fs2
HR(0°, 680-890±7nm)>99.8%, GVD (0°, 720-880nm)~+80±30fs2
HR(0°,680-1100nm)>99.8%, not GVD optimized
HR(0°,680-1100nm)>99.8% + HT(0°,488-532nm)>90%
HR(0°,690-820nm)>99.9% + R(0°,488-532nm)<5%, GVD<20fs2
HR(0°,690-880nm±10nm )>99.9% + R(0°,500-550nm)<2%, GVD<20fs2 (710-870±10nm)
HR(0°, 690-890±5nm)>99.9% + R(0°, 532nm)<2%, GDD(0°, 700-880±10nm)~0fs2
HR(0°,690-960nm±10nm)>99.9% + R(0°,500-540nm)<5%, GDD~0fs2(690-880±10nm)
HR(0°,700-840nm)>99.95%, GVD<20fs2
HR(0°, 700-850nm)>99.8% + HT(0°, 514-532nm)>95%, GVD~0fs2
HR(0°,700-870±7nm)>99.9%, |GDD|<40fs2
HR(0°, 700-870±8nm)>99.9%, GDD=-40±15fs2(725-880nm)
HR(0°, 700-880±8nm)>99.9% + R(0°, 450-550nm)<2%, GVD<20fs2 (710-870±8nm)
HRr(0-45°,700-890±10nm)>99.9% (not GVD-optimized)
HR(0°,700-900nm)>99.8%, GDD<40fs2
HR(0°,700-900nm)>99.9%, GVD(700-900)~ -50±20fs2 (GVD-oscillation compensated)
HR(0°, 700-900nm)>99.9%, GVD(780-805nm)~-550±50fs2
HR(0°,700-900nm)>99.9%, GVD<40fs2
HR(0°,700-900nm)>99.8% + R(0°,532nm)<2%, GDD~0fs2
HR(0°, 700-950±5nm)>99.9% + R(0°, 505-535nm)<10%, GVD~ -50±20fs2(680-940±5nm)
HR(0°, 700-970nm)>99.85%, GDD(700-950nm)~ -60....-30fs2 (GDD - oscillation compensated and TOD optimized)
HR(0°,700-980nm)>99.9% + R(0°,510-532nm)<10%, IGDD(R,0°,710-870nm)I<30fs2
HR(0°,700-1000nm)>99.9%, GDD-R(0°,700-1000nm)=-50±50fs2
HR(0°,700-1030nm)>99.8%, GVD(730-1000nm)=-60±20fs2
HR(0°, 705-920±8nm)>99.9%, GVD~-40±15fs2
HR(0°, 710-850±8nm)>99.9% + R(0°,350-400±5nm)<3%
HR(0°,710-860nm)>99.9% + R(0°,480-570nm)<2%, GVD<20fs2
HR(0°, 710-880±5nm)>99.9%, GDD<20fs2
HR(0°, 710-890±8nm)>99.9% + R(0°,480-550±5nm)<3%, GVD<20fs2
HR(0°, 710-900±8nm)>99.9% + R(0°, 510-550nm)<5%, GVD=-40±10fs2
HR(0°, 710-940±8nm)>99.9%, GVD(0-12°, 740-870nm)~-350fs2....+350fs2, increasing arithmetically
HR(0°, 710-950±8nm)>99.9% + R(0°, 500-550nm)<2%, GVD(0-12°, 700-1000nm)~0...-300fs2
HR(0°, 715-820nm)>99.9%, GDD<20fs2
HR(0°,720-870nm)>99.9%, |GVD|<20fs2
HR(0°, 720-880nm)>99.9%, GVD(0°, 760-840nm)~+150fs2....-100fs2 (linear decreasing)
HR(0-12°, 720-880±8nm)>99.9%, GVD~-40±10fs2
HR(0°,720-880nm)>99.99%, GDD(0°,720-880nm)~ -10±10fs2
HR(0°,720-880±8nm)>99.9% + R(0°,514-532nm)<5%, GVD=-40±10fs2
HR(0°, 720-920nm)>99.9%, GVD(790-815nm)~ -550±50fs2
HR(0°,720-920nm)>99.8% + R(0°,532nm)<5%, GDD~0fs2 (730-900nm)
HR(0°,720-940±5nm)>99.9% + R(0°,520-560nm)<5%, GVD=-40±10fs2
HR(0°,720-1210+/-10nm)>99.9%, GD~0-100fs
HR(0°,725-930±5nm)>99.9%, GVD (735-910nm)<20fs2
HR(0°,730-860±8nm)>99.9% + R(0°,500-550nm)<3%, GVD<20fs2
HR(0°, 730-870nm)>99.8%, GVD(0°, 630-890nm)~-40fs2±15fs2 , (GVD-oszillation compensated)
HR(6°, 730-870nm)>99.8%, GDD=115±35fs2
HR(0°,730-880±10nm)>99.9%, GVD<20fs2
HR(0°,730-890±7nm)>99.9%, GVD<20fs2
HR(0°,730-900nm±10nm)>99.8% + R(0°,532nm)<5%, GVD~-50±10fs2(750-920nm)
HR(0°, 730-1030±5nm)>99.8% + R(0°, 650-690nm)<5%, GVD~-50±40fs2( 750-920nm)
HR(0°, 740-840nm)>99.9%, |GDD-R(0°, 740-840nm)|<20fs2
HR(0°,740-840nm)>99.75% + GDD(0°,750-830nm)~450(±150)fs2
HR(0°,740-860nm)>99.9%, GDD<50fs2
HR(0°,740-860nm)>99.9%, GVD<20fs2
HR(0°,740-910nm)>99.8%, GDD(0°,750-910nm)~ -45±10fs2
HR(0°,740-950±5nm)>99.9%, GDD (760-930nm)<20fs2
HR(0°,750-850nm)>99.9% + R(0°,532nm)<1%
HR(0°, 750-850nm)>99.9% + R(0°, 532nm)<3%, GDD-R(0°, 750-840±5nm)=-120±40fs2
HR(0°,750-850nm)>99.9% + R(0°,670nm)<5%
HR(0°,750-850nm)>99.9%, |GDD|<20fs2
HRs,p(0-20°,750-850nm)>99.9%, |GDD|<20fs2
HR(0°, 750-870±8nm)>99.9% + R(0°, 360-480nm)<5%
HR(0°, 750-900nm)>99.9%, /GDD/~ -45±10fs2
HR(0°,750-920nm)>99.9% + R(0°,520-580nm)<2%, GVD<20fs2
HR(0°,750-920nm)>99.9%, GDD<20fs2
HR(0°,750-930nm)>99.9%, GVD<20fs2
HR(0°,750-1250nm)>99.9%
HR(0°,760-860nm)>99.9% + R(0°,380-430nm)<5%, GVD<20fs2
HR(0°, 760-930±8nm)>99.95%, GVD~-20±10fs2(0°, 740-860nm)
HRp(0-10°, 770-830nm)>99.9%, GDDp(0-10°, 770-830nm)~-150±30fs2
HR(0°,770-940+/-8nm)>99.9% + R(0°,490-550nm)<5%, GVD(0°,770-940nm)<20fs2
HR(0°,770-970nm)>99.9%, GDD<40fs2
HR(0°,780-900±8nm)>99.9% + R(0°, 390-420±4nm)<3%, GVD<20fs2
HR(0°,780-940nm)>99.9%, GVD<20fs2
HR(0°,800-880nm)>99.9% + R(0°,532nm)<2%, GVD<20fs2
HR(0°,800-900nm)>99.9% (High Power)
HR(0°,800-900nm)>99.9%, GVD<20fs2
HR(0°,800-900nm)>99.9% + R(0°,685nm)<2%, GVD<20fs2 (High Power)
HR(0°,820nm)>99.9%
HR(0°, 830-950±8nm)>99.9%, GVD<20fs2
HR(0°,840-920nm)>99.9% + R(0°,410-470nm)<10%, |GDD-R(0°, 840-920nm)|<20fs2
HR(0°,840-920nm)>99.9% + R(0°,410-470nm)<5%, GVD<20fs2
HR(0°, 840-1050nm)>99.9%, GVD(890-980nm)~-65±15fs2
HR(0°, 870-1180±10nm)>99.9%, GVD(0-10°, 1064nm)~ -1000±100fs2
HR(0°,900-1000nm)>99.9%
HR(0-10°, 900-1000nm)>99.95% + R(0-10°, 450-500nm)<5%
HR(0-10°, 900-1100±10nm)>99.8%, GVD(1040-1090nm)~-550±100fs2
HR(0-3°, 900-1100±10nm)>99.9%, GVD(1028±10nm)~-550+50/-75 fs2
HR(0°,900-1100±10nm)>99.9%, GDD<20fs2
HR(0-12°, 900-1120nm±10nm)>99.9%, GVD(0-12°, 1030-1040±5nm)~ -450±50fs2
HR(0°, 920-1140±10nm)>99.9%, GVD(990-1050nm)~ -250±50fs2
HR(0°, 930-1130nm±10nm)>99.9%, GVD(1020-1070±5nm)~ -375±50fs2
HR(0°, 930-1140±9nm)>99.9% with Rmin~99.7% at 1033±5nm (see data sheet), GVD (990-1110±5nm) ~ -100fs2±20fs2
HR(0°, 940-1090±10nm)>99.9%, GVD(1000-1065±5nm)~-100fs2±20fs2
HR(0°,940-1100nm)>99.9%, GDD<20fs2
HR(0-10°,940-1100nm)>99.9%, GVD(1020nm)~ -320±50fs2, GVD(1060nm)~ -250±50fs2
HR(0-10°, 940-1110nm±10nm)>99.9%, GVD(0-10°,1010-1080nm)~ -250±50fs2
HR(0-10°, 940-1110nm±10nm)>99.9%, GVD(0-10°,1020-1030nm)~-1300±150fs2
HR(0°, 940-1180±5nm)>99.9%, GVD(990-1120nm)~ -55±10fs2
HRp(0-10°, 940-1140±10nm)>99.9%, GVDp(0-10°,1035±10nm)~+1000±200fs2
HR(0°, 940-1140±10nm)>99.9%, GVD(980-1130±5nm)~ -100fs2±20fs2
HR(0°,940-1150nm)>99.9%, GVD(0°,930-1150nm)~ -55±15fs2
HR(0-10°,950-1120±10nm)>99.9%, GVD(0-10°,1030nm)~ -550±50fs2
HR(0-15°,950-1120±10nm)>99.9, GVD(0-10°,1040nm)~ -550±50fs2
HR(0°,950-1130±10nm)>99.8±0.5%, GVD(0°,1030nm)~ -1200±50fs2
HR(0-10°, 950-1150±10nm)>99.9%, GVD(0-10°, 1030-1040nm)~ -550±50 fs2
HR(0-15°, 950-1140±10nm)>99.9%, GDD(1030-1040nm)~ -550±50 fs2
HR(0-10°, 950-1170nm±10nm)>99.9%, GVD(0°, 1000-1080nm)~ -250±75fs2
HR(0-12°, 950-1200nm±10nm)>99.9%, GVD(0-12°, 1030nm)~ -250±50fs2
HR(0°,1040nm)~99.85...99.9%, GVD(0°,1020-1035nm)~-1300±150fs2
HR(0°,1040nm)~99.85...99.9%, GVD(0°,1025-1045nm)~ -1300±150fs2
HR(0°,1040nm)~99.85...99.9%, GVD(0°,1035-1050nm)~-1300±150fs2
HR(0°, 960-1140±10nm)>99.9%, GVD(0°, 1030nm)~-1300±200fs2
HR(0°, 960-1200nm±10nm)>99.9%, GVD(1020-1080±5nm)~ -200±50fs2
HR(0-10°, 960-1220nm±10nm)>99.9%, GVD(0-10°, 1020 - 1080nm)~ -250±75fs2
HR(0-3°, 970-1100±10nm)>99.95%, GVD(1030nm)~-800±75fs2, GVD(1060nm)~0fs2, for TOD-management
HR(0°, 970-1120nm)>99.9%, GDD(0-10°,1040nm)~ -1300±150fs2
HR(0-10°, 970-1170±10nm)>99.9%, GVD(0-10°,1005-1025nm)~-950±125fs2
HR(0-14°, 970-1170±10nm)>99.9%, GVD (0-14°, 1045nm) ~ -1200±100fs2
HR(0-10°,970-1200±7nm)>99.9%, GVD(0-10°,1064nm)~-650±100fs2
HR(0-10°, 970-1250nm±10nm)>99.9%, GVD(0-10°,1025-1100nm)~-250±50fs2
HR(0-12°, 976nm)>99.9% + R(0-12°, 488nm)<5%
HR(0-10°, 980-1110nm±10nm)>99.85%, GDD(0-10°, 1030nm)~ -900±100fs2
HR(0-10°,980-1120nm)>99.9%, GDD(0-10°,1020-1080nm)~ -300±50fs2
HR(5°, 980-1130nm)>99.7%, GVD(1035nm)~+1800±100fs2
HR(0°,980-1150±10nm)>99.9%, GVD(0°,1040-1070nm)~ -500±50fs2
HR(0-10°,980-1150±10nm)>99.8%, GVD(0°/10°,1042nm/1036nm)~ -550±50fs2
HR(0-10°, 980-1170nm)>99.8%, GVD(1010nm)~-600±50fs2, GVD(1080nm)~-350±50fs2
HR(0°, 980-1460±10nm)>99.8%, GVD(1000-1500nm)~ -120±40fs2 , (GVD-Oszillation compensated)
HR(0-5°, 990-1060±10nm)>99.6%, GVD(0-5°, 990-1060nm)~-600....-350fs2
HR(0-10°, 990-1130nm)>99.9%, GDD(0-10°,1030nm)~ -900±100fs2
HR(0-10°, 990-1180nm)>99.9%, GVD(1045±10nm)~ -800±100fs2
HR(0-10°, 990-1250nm±10nm)>99.9%, GVD(0°,1030-1090nm)~-250±50fs2
HR(0-10°,1000-1130±8nm)>99.9%, GVD(0-10°,1030nm)~ -1000±100fs2
HR(0-12°, 1000-1160±9nm)>99.9%, GVD(0-12°,1064nm)~ -1000+100-200fs2
HR(0-10°,1000-1230nm)>99.9%, GVD(0°,1100-1140nm)~-500fs2±50fs2
HR(0°,1000-1450nm±15nm)>99.75% + R(0°,680-930nm)<10%
HR(0°, 1000-1600±10nm)>99.8% + R(0°, 700-950nm)<10%, GVD~-300....0fs2 (GVD optimized for OPO-application)
HR(0°,1010-1064nm)>99.9% + R(0°,935-980nm)>99%
HR(0°,1010-1070nm)>99.9% (High Power)
HR(0°,1020-1060nm)>99.9%, |GDD|<20fs2
HR(0°,1020-1080nm)>99.9%, |GDD|<20fs2
HR(0°, 1020-1650±10nm)~99.9%, GVD~ -200fs2 at 1080nm...0fs2 at 1650nm (GVD optimized for OPO-application)
HR(6°,1030nm)>99.9%, GDD(6°,1030nm)~ -10 000fs2 (+3000/-8000fs2)
HR(0°, 1030nm)>99.95%, GVD(0-4°,1030nm)~ -1300±150fs2
HR(0°, 1030nm)>99.98%, GDD-R(0°,1030nm)~(-550±50)fs2
HRs(8°,1030-1045nm)>99.95%, GDD(8°, Rs,1030-1045nm)= -1200±200fs2
HR(0-10°,1040-1042nm)>99.9%, GDD(0-10°, 1040-1042nm)=-10000 +/-2500 fs2
HR(0-10°,1047nm)~99.93...99.94%, GVD(0-10°,1047nm)~ -1000±150fs2
HR(0°,1050-1064nm)>99.9%, GDD(0-12°,1050-1064nm)~ -1300±150fs2
HR(0°,1050-1200nm)>99.9% + R(0°,740-830nm)<5%, GVD<20fs2
HR(0-10°,1050-1290nm)>99.9%, GVD(0°,1090-1180nm)~ -200fs2±50fs2
HR(0-10°,1050-1300nm)>99.9%, GVD(0°,1090-1160nm)~ -350fs2±50fs2
HR(0°, 1060-1600nm)>99.8%, GDD~ -150±100fs2 (GDD optimised for OPO-application)
HR(0°,1064nm)>99.9% + R(0°,532+808nm)<5%
HR(0°,1090-1400nm±15nm)>99.9%, GVD(1170-1380±15nm)~-150±25fs2
HR(0°,1120-1420nm±10nm)>99.9% + R(0°,1030nm)<10%, GVD~ -70±20fs2(1150-1380nm±10nm)
HR(0°,1130-1420nm±15nm)>99.9%, GVD(1200-1300±15nm)~-250±75fs2
HR(0°,1170-1470nm±5nm)>99.8% + R(0°,1040-1090nm±5nm)<10%, GVD~-60±10fs2(1200-1400nm±10nm)
HR(0°,1290-1650nm±20nm)>99.9% + R(0°, 1050-1100nm)<5%, GVD~ -150...0fs2(1350-1600nm)
HR(0°,1300-1350nm)>99.9% + HR(0°,1325±10nm)>99.95% (High Power)
HR(0°,1375-1575nm)=99.8±0.05%, GDD<30fs2
HR(0-10°,1400-1700nm)>99.85%, GVD(0-10°,1480-1530nm)~ -500fs2±50fs2
HR(0°, 1400-1800nm)>99.8% + R(0°, 1000-1100nm)<3%, GVD (0°, 1400-1800nm)~0....-400fs2, optimized for OPO - application
HR(0°,1420-1720nm)>99.9% + R(0°,870-1050nm)<2%, |GDD|<40fs2 (1440-1700nm)
HR(0°, 1450-1700±10nm)>99.9% + R(0°, 950-1000nm)<3%, GVD (0°, 1500-1700±10nm)~-120fs2, optimized for OPO - application
HR(0°,1550-1615nm)>99.99%, T(0°,1580nm)~0.002% (Low Loss)
HR(0°, 1600-1700nm)>99.99% low loss, T (0°, 1650nm)~0.0008%, single stack like
HR(0°,1800-2075±20nm)>99.9% + R(0°, 808 + 980nm)<2%
HR(0°,1850-2200nm)>99.9%
HR(0°, 3300nm)>99.9%, GDD(0°, 3300nm)<20fs2, single stack like
HR(0°, 840-1160±10nm)>99.9%, GVD(0-10°, 1040nm)~ -1000±100fs2
HRs(30°,210-225nm)>97% + Rs(30°,410-450nm)<5% (fluoridic)
HRs(0-22.5°,390nm)>99.9% + PRs(0-22.5°,700nm)=20±2%
HRs+p(22.5°,405nm)>99.9% + Rs+p(22.5°,810nm)<5%, GVD<20fs2
HRs(12°,1030nm)>99.9%, GVDs(12°,1030nm)~ -1300±200fs2
HRs(30°,1370-1750±5nm)>99.9%, GVDs(1600nm)~ -250fs2
HRs(30°,1480-1680±15nm)>99.9%, GVDs(1590nm)~ -550fs2
HRs(30°,1520-1740±15nm)>99.9%, GVDs(1580nm)~ -100fs2
HRs(30°,2.25-2.6μm)>99.5%+ Rs(30°,1064nm)<1%
HRr(45°,200nm)>95% (fluoridic)
HRr(45°,205nm)>95% + Rs(45°,410nm)<10%
HRr(45°,210nm)>95% (HRs(45°,205-215nm)>97%, HRp(45°,210nm)>93%) + Rp(45°,840nm)<2% (fluoridic)
HRs(45°, 210-235nm)~90% + Rp(45°, 300-1000nm)<8%, |GDD-Rs(45°, 210-235nm)| optimised
HRp(45°,252-268nm)>99.0%
HRr(45°,266nm)>99.5%
HRr(45°,270nm)>99% + Rr(45°,405+810nm)<10%
HRr(45°,266nm)>99.6%
HRs,p(45°,266nm)>98% + HRs,p(45°,400+800nm)>99%, GDD-optimiert
HRr(45°,270nm)>99.5%
HRr(45°,270nm)>99.6%
HRr(45°,270+405nm)>99%
HRs(45°,270-310nm)>99% + Rs+p(45°,390-430nm)<3%
HRr(45°,280nm)>99.5%
HRp(45°,280nm)>98% + Rp(45°,420+840nm)<3%
HRs(45°, 280-330nm)>99.5% + Rp(45°, 440-770nm)<1%, |GDD-Rs(45°, 280-330nm)|<20fs2, |GDD-Rp(45°, 285-330nm)|<20fs2, |GDD-Ts,p(45°, 440-770nm)|<10fs2
HR(0°, 285nm)>99.8% Low Loss, T(0°, 285nm)~0.03%
HRr(45°,285nm)>99.7%
HRs(45°, 320-470nm)>99.5% + Rp(45°, 600-950nm)<2%, GVD - optimiert
HRs(45°, 325-600nm)>99.5% + HRp(45°, 325-600nm)>98% typically Rp>98.5%, GDD-Rp(45°, 325-600nm)<100fs2
HRp(45°, 330-370±5nm)>99.8% + Rs(45°, 480-580±5nm)<2% + Rp(45°, 1000-1100nm)<2%
HRs(45°, 330-390nm)>99.5% + Rp(45°, 440-770nm)<1%, |GDD-Rs(45°, 330-390nm)|<20fs2, |GDD-Rp(45°, 340-380nm)|<20fs2, |GDD-Ts,p(45°, 440-770nm)|<10fs2
HRs(45°, 330- 470±4nm)>99.8%, HRp(45°, 370- 450±4nm)>99.6% + HRs(45°, 680- 950±8nm)>99.8%, HRp(45°, 700- 900±8nm)>99.6%, GVD opt. for s+p-pol. at 400nm and for p-pol. at 800nm
HRs(45°, 340-355nm)>99.5% + Rp(45°,515-530nm)<5% + Rs(45°,1020-1060nm)<10%
HRp(45°,340-500nm)>99%, |GDD-Rp(45°,340-500nm)|<60fs2
HRs(45°, 340-650nm)>99.5% typically Rs>99.8%, GDD-Rs(45°, 300-650nm)<200fs2
HRs(45°, 355nm)>99.0% + Rp(45°, 532 + 1064nm)<2% + Rs(45°, 532 + 1064nm)<10%
HRs(45°, 360-440±5nm)>99.9% + HRp(45°, 370-420±5nm)>99.8% + Rs+p(45°, 500-900nm)<5%, GVD<20fs2
HRp(45°,360-440nm)>99.7%, |GDD(Rp,45°,360-440nm)|<100fs2
HRs(45°, 360-445nm)>99.9%+HRp(45°,375-425nm)>99.8% + Rs+p(45°,500-930nm)<5%, with Rs + Rp<2% at 800nm, GDD(R+T)<20fs2
HRs(45°, 365-545nm)>99.9% + HRp(45°, 395-515nm)>99.7%, GDDp - optimized
HRr(45°,370-410nm)>99.8%, /GDD/<20fs2
HRr(45°,370-420nm)>99.9% + Rr(45°,600-980nm)<2%, /GDD/<20fs2
HRs+p(45°,375-425nmnm)>99.8% + Rs+p(45°,750-850nm)<5%, GVD<20fs2
HRr(45°,380-420nm)>99.8%, |GDD|<20fs2
HRs+p(45°, 400nm)>99.9%+Rp(45°, 500-900nm)<2%
HRp(45°, 400nm)>99.9%+Rp(45°, 900-1800nm)<2%, |GVD-Rp(45°,380-420nm)|<20fs2, |GVD-Tp(45°,900-1800nm)|~0fs2
HRr(45°, 405+810nm)>99.9%
HRs+p(45°,405nm)>99.9% + Rs+p(45°,810nm)<5%, GVD<20fs2
HRp(45±3°, 450-900nm±5nm)>99.0...99.8%, GVDp(45±3°, 470-890nm)~ -50±20fs2 (angle tuning suggested to achieve optimal GVD compensation)
HRs(45°,470-570nm)>99.9% + Rs+p(45°,700-1100nm)<5%, GVD<20fs2
HRr(45°, 515±10nm + 1030±20nm)>99.9%
HRs,p(45°,520nm)>99.9% (high power), |GDD-Rs,p(45°,520nm)|<10fs2
HRs+p(45°,625-645nm)>99.9% + Rs+p(45°,430-450nm)<3%
HRs(45°,630nm)>98.5% + Rp(45°,1270nm)<2%, GVD(T + R)<20fs2
HRr(45°, 630-1100±8nm)>99.8%
HRs(45°, 630-1100nm±8nm)>99.9%, GVD(s-pol. reflection 45°, 630-1100nm)<200fs2
HRp(45°, 640-940nm)>99.8%, GDD-Rp(45°, 640-940nm)~ -60±30fs2, oscillation compensated
HRs(45°, 650-980nm±7nm)>99.8%, GVD(s-pol. reflection 45°, 660-870nm)<30fs2
HRs(45°, 650-1150nm)>99.9% + HRp(45°, 670-1085nm)>99.7%, with smoothed GD
HRp(45°,660-1100nm)>99.8%, GVD-Rp(45°,660-1100nm)|<160fs2, GD smoothed
HRp(45°, 680-980+/-8nm)>99.9%, GVDp-optimized
HRs(45°, 680-1000nm)>99.9%, GDD(s-pol. reflection 45°, 690-920nm)<20fs2
HRr(45°, 680-1100nm)>99.8%
HRr(45°, 690-820nm±8nm)>99.9%, GVD(Rs + Rp)<20fs2
HRs(45°, 690-1000+/-8nm)>99.9%, GVDs-optimized
HRp(45°, 700-860±6nm)~99.7%, GVDp~0....-200fs2
HRs+p(45°, 700-900+/-10nm)>99.9% + Rp(45°, 350-450+/-5nm)<7%, GVD optimiert für Tp + Rp (siehe Datenblatt)
HRs(45°,700-1000nm)>99.9%, GDD-Rs(45°,700-1000nm)<120fs2
HRs(45°,700-1000nm)>99.95%, GDD-Rs(45°,700-1000nm)=-50±50fs2
HRp(45°, 700-1010+/-8nm)~99.9%, GDp-optimized
HRr(45°,720-850nm±10nm)>99.9%, GVD(Rs + Rp)<20fs2
HRs(45°,730-830nm)>99.99%, |GDD|<20fs2
HRs(45°, 730-850nm±8nm)>99.9%, GDD-Rs(45°, 730-850±8nm)~ -40±20fs2
HRr(45°,720-880±10nm[Rs(45°, 690-935nm) + Rp(45°, 725-875nm)])>99.9%, GVD(Rs700-920 + Rp740-860nm)<20fs2
HRr(45°,740-820±5nm)>99.9%, GVD<20fs2
HRs(45°,740-840nm)>99.9% + Rp(45°,860-1600nm)<5%, GDD-optimised
HRr(45°,740-860nm)>99.9%, GVD<20fs2
HRr(45°, 740-880nm)>99.9%, GDD<20fs2
HRr(45°,750-850nm)>99.9% + Rr(45°,532nm)<5%, GVD<20fs2
HRp(45°,750-850nm)>99.5% + HRs(45°,750-850nm)>99.8%, GVD<20fs2
HRr(45°,750-850nm)>99.9%, GDD<20fs2
HRs,p(45°, 750-850nm)>99.9%, |GDD-Rs,p(45°, 750-850nm)|<20fs2
HRr(45°,760-850nm±5nm)>99.9% + Rr(45°,360-440nm±5nm)<2%, GVD<20fs2
HRr(45°,760-900±8nm)>99.9%, GVD<20fs2
HRs(45°,760-920nm)>99.9% + Rs+p(45°,550-700nm)<5%, GVD(T)<25fs2
HRr(45°,765-880nm)>99.8%, GVD<20fs2
HRr(45°,770-860nm)>99.9% + Rr(45°,380-430nm)<5%, GVD<20fs2
HRs+p(45°,800±20nm)>99.9% + Rs+p(45°,400±10nm)<5%, GVD<20fs2
HRp(45°,808nm)>99.9% + Rs(45°,1200-1600nm)<5%, GDD<20fs2
HRs(45°,800nm)>99.9% + Rp(45°,1200-2800nm)<3%, GDD<20fs2
HRr(45°,800-900nm)>99.8%, GVD<20fs2
HRr(45°,840-940±8nm)>99.9%, GVD<20fs2
HRr(45°,870-990nm)>99.9%, GDD<20fs2
HRr(45°,880-990nm)>99.9%, GDD<20fs2
HRr(45°,890-1000nm)>99.9%, GDD<20fs2
HRp(45°,960-1440nm±15nm)>99.7%, GVD(1170-1380±15nm)~-200±100fs2
HRr(45°, 970-1110nm)>99.9%, GDD optimised
HRs(45°, 1030nm)>99.9%, GVDs(45°,1030nm)~ -1300±200fs2
HRr(45°,1064nm)>99.8% + HRr(45°,1450-2000nm)>99% + HTr(45°,2300-4000nm)
HRr(45°,1160-1350nm±10nm)>99.9%, GVD<20fs2
HRp(45°,1470-1570±10nm)>99.9%
HRp(45°,1490-1590nm±10nm)>99.9%
HRr(45°,1550±50nm)>99.9%
HRs(45°, 2170-2230±20nm)>99.9% + Rp(45°, 1064nm)<5% + Rp(45°, 2040-2070nm)<5%
HRs(45°,2090nm)>99.9%
HRs(45°, 2096nm)>99.9% + Rs+p(45°, 800nm)<10% + Rs+p(45°, 1907nm)<5%
HRs(45°,2096nm)>99.8% + Rs+p(45°,1907nm)<5%
HRs(50°-80°, 266nm )>99.2% + HRs(50°-80°, 400nm)>99.5%
TFP(65-70°, 266nm) Rs>97% Rp<10%, angle tuning suggested to achieve Tp(max)
TFP(54°, 346nm) Rs>99.5% Rp<2%
TFP(57°,390nm) Rs>99.8% Rp<2%
TFP(56°,400nm) Rs>99.8% Rp<2%
TFP(54°, 520nm) Rs>99.9% Rp<2%
TFP Rs(70°, 600-1000nm)=80(±4)% Rp(70°, 600-1000nm)<5%, |GDD-Rs(70°,600-1000nm)|<5fs2
TFP Rs(80°, 700-900nm)>94% Rp(80°, 710-890nm)<5%, |GDD-Rs(80°,700-900nm)|<5fs2
TFP(65±5°, 760-840nm) Rs>99.8% Rp<2%
TFP(55°,750nm) Rs>99.9% Rp<2%
TFP(65±2°, 750-825nm) Rs>99.8% Rp<2%(65±2°, 765-850nm), GVDs+p opt.
TFP(55°+/-1°, 915nm) Rs>99.9% Rp<2%
TFP(55°+/-1°, 943nm) Rs>99.9% Rp<2%
TFP(56±3°,1035-1055nm) Rs>99.8% Rp<2% (with angle adjustment ±3°)
TFP[55°(±3°)*, 1550nm] Rs>99.9% Rp<2% (*angle adjustment for optimising working point)
PR(0°,310-430nm±10nm)=99±0.3%
PR(0°, 420nm)=95±0.5%
PR(0°,420-640nm±10nm)=99±0.5%
PR=99.5±0.3%(0°, 430-690±8nm), GVD(0°, 430-690nm)~-20±20fs2, (GVD-oscillation compensated)
PR(0°, 480-720nm)=86±2%, GVD optimized
PR(0°,500-750nm)=90±2%, GVD<20fs2
PR(0°,540-620nm)=90±2%
PR(0°,580-870nm)=50±3%, GVD<20fs2
PR(0°, 600-1000nm)=20±4%, GDD(T + R)<20fs2
PR(0°, 630-730nm)=96±2% + PR(0°, 760-880nm)=90±2% + PR(0°, 980-1080nm)=96±2%
PR(0°,630-1050nm)=97±1%
PR(0°,630-1120nm)=97±1%
PR(0°,640-700nm±10nm)=99±0.5%
PR(0°, 640-1050nm)=89±2%, GDD optimised
PR(0°, 640-1100nm)=90±2%, GVD optimized
PR(0°, 650-1100nm)=80±5% + R(0°, 488-532nm)<5%, GVD opt.
PR(0°,660-920nm)=70±2%, GVD<50fs2
PR(0°,660-920nm)=80±2%, GVD<50fs2
PR(0°,660-920nm)=85±2%, GVD<50fs2
PR(0°,660-920nm)=90±2%, GVD<50fs2
PR(0°,660-920nm)=95±2%, GVD<50fs2
PR(0°,660-920nm)=97±0.75%, GVD<50fs2
PR(0°,660-920nm)=98±0.5%, GVD<50fs2
PR(0°,660-920nm)=98±0.75%, GVD<50fs2
PR(0°,660-920nm)=99±0.3%, GVD<50fs2
PR(0°,660-920nm)=99±0.5%, GVD<50fs2
PR(0°,660-920nm)=75±2%, GDD<50fs2
PR(0°, 680-730nm)=96±1% + PR(0°, 800-900nm)=90±1% + PR(0°, 950-1100nm)=96±1%
PR(0°,680-1100nm)=85±3%
PR(0°,680-1100nm)=90±2%
PR(0°,680-1100nm)=92±2%
PR(0°,680-1100nm)=95±1%
PR(0°,680-1100nm)=96±1%
PR(0°,680-1100nm)=97±1%
PR(0°,680-1100nm)=98±1%
PR(0°, 680-1100nm)=99±0.3%, GDD optimized
PR(0°,680-1100nm)=99±0.5%
PR(0°,700-850±7nm)=97±0.5%, GVD~0fs2
PR(0°,700-900nm)=80±3%, GDD~0fs2
PR(0°,700-900nm)=85.0±1.5%, |GDD|<20fs2
PR(0°,700-900nm)=85±3%, GDD<20fs2
PR(0°,700-900nm)=85±3%, GVD<20fs2
PR(0°,700-900nm)=90±2%, GVD<20fs2
PR(0°,700-900nm)=93±2%, GDD<40fs2
PR(0°,700-890nm)=95±2%, GVD<20fs2
PR(0°,700-900nm)=95±1%, GVD<20fs2
PR(0°,700-900nm)=97±0.75%, GVD<20fs2
PR(0°,700-900nm)=98±0.5%, GVD<20fs2
PR(0°,700-900nm)=99±0.3%, GDD<20fs2
PR(0°, 730-870±8nm)=98.8±0.3%, GVD~20fs2
PR(0°,730-870±8nm)=99.0±0.15%, GDD~20fs2
PR(0°,730-870±8nm)=99.75±0.1%, GVD~20fs2
PR(0°, 730-900±8nm)=90.0±2%, GVD<20fs2
PR(0°, 740-860±8nm)=99.5±0.15%, GVD~20fs2
PR(0°,750-850nm)=85±3%, GVD<20fs2
PR(0°,750-850nm)=86±2%, GVD<20fs2
PR(0°,750-850nm)=88±2%, GVD<20fs2
PR(0°,750-850nm)=90±2%, GVD<20fs2
PR(0°,750-850nm)=93±1%, GVD<20fs2
PR(0°,750-850nm)=94±1%, GVD<20fs2
PR(0°,750-850nm)=95±0.75%, GVD<20fs2
PR(0°,750-850nm)=97±1%, GVD<20fs2
PR(0°,750-850nm)=98±0.5%, GDD<20fs2
PR(0°,750-850nm)=99.75±0.10%, |GDD|<20fs2
PR(0°,750-850±8nm)=99.9±0.05%, |GDD|<20fs2
PR(0°,750-850nm)=99.0±0.3%, GDD<20fs2
PR(0°, 750-850nm)=50±3%, |GDD|<20fs2
PR(0°, 750-850nm)=70±3%, |GDD|<20fs2
PR(0°,750-920nm)=95±1%, GVD<20fs2
PR(0°,770-800nm)=98.8±0.2%, GVD<20fs2
PR(0°,770-800nm)=98±0.2%, GVD<20fs2
PR(0°,770-870+/-8nm)=95±0.75%, GVD<20fs2
PR(0°,770-870+/-8nm)=97±0.5%, GVD<20fs2
PR(0°,780-850nm)=95±1%, |GVD|<20fs2
PR(0°,780-850nm)=98±0.5%, GVD<20fs2
PR(0°,795+950nm)=99.85±0.075%
PR(0°, 800nm±50nm)=87±1%, GVD<20fs2
PR(0°,840-920nm)=98±1%, GVD<20fs2
PR(0°,850nm)=40±1%, GVD~0fs2
PR(0°,850nm)=60±1%, GVD~0fs2
PR(0°,850nm)=65±1%, GVD~0fs2
PR(0°, 850-910nm)=73±3%, GVD<20fs2
PR(0°, 850-910nm)=83±3%, GVD<20fs2
PR(0°, 850-910nm)=90±2%, GVD<20fs2
PR(0°,860nm)=92.5±0.2%
PR(0°,860nm)=93.7±0.2%
PR(0°, 930-1140nm)=99.5±0.3%
PR=99.0±0.5% (0°, 950-1450±10nm), GD optimized for OPO-application
PR(0°, 980-1080nm)=90±2%, GVD<20fs2
PR(0°, 980-1080nm)=97±0.75%, GVD<20fs2
PR(0°,980-1110nm)=97.5±0.5%, GVD<20fs2
PR(0°,1000-1100nm)=97.5±0.5%, GDD<20fs2
PR(0°,1000-1100nm)=90±1%, |GDD-R(0°, 1000-1100nm)|<40fs2
PR(0°,1000-1100nm)=85±1%, |GDD-R(0°, 1000-1100nm)|<40fs2
PR(0°,1000-1100nm)=80±2%, |GDD-R(0°, 1000-1100nm)|<20fs2
PR(0°,1000-1100nm)=92.5±1.0%, |GDD(0°, 1000-1100nm)|<40fs2
PR(0°,1030-1064nm)=99.7±0.15%
PR(0°, 1040±50nm)=95±0.75%, GVD<20fs2
PR(0°, 1040±50nm)=97.6 -0.1+0.4%, GVD<20fs2
PR(0°, 1040±50nm)=98.4 -0.3+0.1%, GVD<20fs2
PR(0°, 1040±50nm)=99.2 -0.1+0.4%, GDD<20fs2
PR(0°, 1040±50nm)=99.6±0.1%, GVD<20fs2
PR(0°, 1040±50nm)=99.8±0.1%, GVD<20fs2
PR(0°,1300-1350nm)=96±1%
PR=85.0±3% (0°, 1400-1800±10nm), GVD optimized for OPO-application
PR(0°,1500-1600nm)=99.0...99.3%, |GVD|<40fs2
PR(0°,1535nm)=99.92±0.2%
PR(0°, 1820-2050nm)=85±1%
PR(0°, 1820-2050nm)=91±1%
PR(0°, 1820-2050nm)=95±1%
PR(0°, 1820-2050nm)=97±1%
PR(0°, 1820-2050nm)=98.5±0.5%
PRp(22.5°, 750-850nm)=80±5% + Rp(22.5°, 450-695 + 920-1000nm)<10%
PRp(45°,350-450nm)=50±5% + PRr(45°,630-650nm)=50±5%, GVD<20fs2
PRp(45°,350-470nm)=50±5%, GVD<20fs2
PRs(45°, 360-430nm)=50±3%, GVD~0fs2
PRs(45°, 370-430nm)=50±5%, GVD(R+T)<20fs2
PRp(45°,370-430nm)=50±5%, |GDD-Rp/Tp(45°,370-430nm)|~0fs2
PRp(45°,380-420nm)=60±3%, GVD~0fs2
PRp(45°,380-420nm)=70±3%, GVD~0fs2
PRp(45°,380-420nm)=80±3%, GVD~0fs2
PRp(45°,380-420nm)=99±0.5%, |GDD|<20fs2
PRs(45°,440-1020±10nm)=50±3%, GVD~0fs2
PRs(45°,440-1040nm)=48±2%, GVD~0fs2
PRs(45°,450-1030nm)=51±3%, |GVD|<20fs2
PRp(45°,515-532nm)=90±1%, GVD<20fs2
PRp(45°,520-1100nm)=20±4%, GVD(R+T)<20fs2
PRp(45°,520-1100nm)=10±3%, |GDD-Rp,Tp(45°, 520-1100)|<20fs2
PRp(45°,540-950nm)=80±3%, GVD(R+T)<30fs2
PRs(45°,550-1050nm)=50±4%, GVD~0fs2
PRp(45°,560-1020nm)=33±3%, GVD<20fs2
PRp(45°, 600-1000nm)=20±4%, GDD(T + R)<20fs2
PRp(45°, 600-1000nm)=48±2%, GVD(T + R)<20fs2
PRp(45°,600-1000nm)=50±3%, / GDD< 20fs2/
PRp(45°, 600-1000nm)=50±3%, GDD(T + R)<20fs2
PRp(45°,600-1000nm)=66±3%, GVD<20fs2
PRs(45°,600-1000nm)=80±2%, GVD(R+T)<30fs2
PRp(45°, 600-1000nm)=80±3%, GDD(T + R)<20fs2
PRp(45°, 600-1000nm)=75±3%, |GDD-Tp / Rp|<20fs2
PRp(45°,600-1030nm)=99.0±0.5%, GDDp optimiert
PRp(45°,600-1050nm)=50±5%, GDDp optimiert
PRs(45°,600-1050nm)=99.0±0.3%, GDDs optimiert
PRs(45°,600-1070nm)=50±5%, |GDDs(R+T)|~0fs2
PRp(45°, 600-1220nm)=50±4%, GDD(T + R)<20fs2
PRp(45°,620-1050nm)=48±2%, GVD~0fs2(R+T)
PRp(45°,620-1050nm)=50±2%, GVD~0fs2(R+T)
PRp(45°, 620-1060nm)=67±3%, GVD~0fs2(R+T)
PRp(45°,620-1100nm)=30±3%, GVD~0fs2(R+T)
PRp(45°,630nm)=50±3%, GVD(T + R)<20fs2
PRp(45°,640-940nm)=33±3%, GVD~0fs2
PRs(45°,650-1100nm)=50±3%, |GDD|<20fs2
PRp(45°,660-920nm)=33±3%, GVD~0fs2
PRs(45°, 670-1050nm)=49±2% Rp(45°, 670-1050nm)~20±2%, GVD(R+T)<20fs2
PRp(45°,680-920nm)=50±4%, GVD~0fs2
PRp(45°, 680-1100nm)=20±4%, GDD~0fs2(R+T)
PRp(45°,680-1100nm)=80±3%, GVD~0fs2(R+T)
PRp(45°,700-900nm)=10±2%, GVD~0fs2
PRp(45°,700-970nm)=27±2%, GVD~0fs2
PRp(45°,700-1000nm)=20±2%, GVD~0fs2
PRp(45°,700-1000nm)=7±2%, GVD~0fs2
PRp(45°,700-1000nm)=17±2%, GDD~0fs2
PRp(45°,710-940nm)=7±1.5%, GVD~0fs2
PRp(45°,720-860nm)=80±3%, GDD optimised
PRp(45°,720-860nm)=92±1%, GDD optimised
PRp(45°,720-860nm)=96±1%, GDD optimised
PRs(45°,720-860nm)=90±2%, |GDD|~0fs2
PRp(45°,720-860nm)=90±2%, |GDD|~0fs2
PRp(45°,720-870nm)=50±5%, GVD~0fs2
PRs(45°,730-860nm)=30±3%, GVD<20fs2
PRs(45°,730-860nm)=40±3%, GVD<20fs2
PRs(45°,730-860nm)=60±3%, GVD<20fs2
PRs(45°,730-860nm)=70±3%, GVD<20fs2
PRp(45°,740-860nm)=50±3%, GVD(T + R)<20fs2
PRp(45°,740-860nm)=66±3%, GVD<20fs2
PRp(45°,740-860nm)=75±3%, |GDD|<20fs2
PRp(45°,740-860nm)=90±1%, GDD~0fs2
PRp(45°,740-860nm)=90...94% + PRs(45°,740-860nm)=98...99%, |GVD|<20fs2
PRp(45°,740-860nm)=95±1%, GDD~0fs2
PRp(45°,750-850nm)=10±3%, GVD<20fs2
PRp(45°,750-850nm)=20±3%, GVD<20fs2
PRp(45°,750-850nm)=30±3%, GVD<20fs2
PRp(45°,750-850nm)=30±3%, GVD~0fs2
PRp(45°, 750-850nm)=35(±3)%, |GDD-Rp,Tp(750-850nm)|<20fs2
PRp(45°,750-850nm)=50±3%, GVD<20fs2
PRp(45°,750-850nm)=50±3%, GVD~0fs2
PRp(45°,750-850nm)=60±3%, |GDD|<20fs2
PRp(45°,750-850nm)=63(±3)%, |GDD|<20fs2
PRs(45°,750-850nm)=70±3%, GVD~0fs2
PRp(45°,750-850nm)=75±2%, GVD<20fs2
PRs(45°,750-850nm)=80±3%, GVD~0fs2
PRp(45°,750-850nm)=80±2%, |GDD|<20fs2
PRp(45°,750-850nm)=85±1%, GVD<20fs2
PRp(45°,750-850nm)=87.5(±2)%, |GDD|<20fs2
PRp(45°,750-850nm)=90±3%, |GDD|~0fs2
PRp(45°,750-850nm)=92±1%, GVD<20fs2
PRs(45°,750-850nm)=95±1%, |GDD|<20fs2
PRp(45°,750-850nm)=95±1%, |GDD|<20fs2
PRp(45°,750-850nm)=99±0.5%, |GVD|<20fs2
PRs(45°,750-850nm)=50±3%, /GDD/<20fs2
PRp(45°,800nm)=37±2%, GVD~0fs2
PRp(45°,840-960nm)=30±2%, GVD~0fs2
PRp(45°, 1170-1330nm)=50±3%, GVD(T + R)<20fs2
PRp(45°,1270nm)=50+2%/-5%, GVD(T + R)<20fs2
PRp(55.5°, 785nm)=73±2%, GVD<20fs2
AR(0°,355+532nm)<0.5% + AR(0°,1064nm)<0.2%
AR(0°, 550-1100nm)<1.5% (<1.0% avg.)
AR(0°,600-1000nm)<0.5%
AR(0°,600-1080nm)<0.5%
AR(0°,610-1080nm)<1.0% + AR(0°,630-1030nm)<0.6%
AR(0°,700-900nm)<0.25%
ARr(45°, 700-950nm)<1.5%
AR(0°,1010-1070nm)<0.2%




连续和纳秒激光反射镜

HR(0°,160nm)>=92% +R(0°,266+800nm)<10%
HR(0°,210nm)>96% (fluoridisch)
HR(0°, 230nm)>98%
HR(0°,248nm)>99.5%, T(0°, 248nm)~0.02±0.01%, Low Loss
HR(0°, 252-270nm)>99.6% + HR(0°, 514-545nm)>99.9%
HR(0°,255-275nm)>99.5%
HR(0°,262-266nm)>99.5%
HRr(0°,266nm)>99.5%
HR(0°, 750-850nm)>99.9% + HR(0°, 266nm)>99.2%
HRr(0°,270nm)>99.5%
HR(0°, 308nm)>99.5%
HR(0°,324-339nm)>99.9%
HR(0°,330-340nm)>99.9%
HR(0°,355nm)>99.5% + R(0°,532nm)<5% + R(0°,1064nm)<5%
HR(0°, 710-900±7nm)>99.7% + HR(0°, 345-450±5nm)>99.4%, |GVD|(360-450nm)<50fs2 + GVD(700-900nm)~-150...100fs2
HR(0°, 350-450±5nm)>99% + HR(0°, 710-910±5nm)>99.5%
HR(0°,355nm)>99.9%
HR(0°,355nm)>99.8% + R(0°,700-2000nm)<10%
HR(0°, 360 + 720nm)>99.9%
HR(0°,360-490nm)>99.7%
HR(0°,370-425nm)>99.8%, |GDD|<20fs2
HR(0°,400-450nm)>99.9%
HR(0°,473nm)>99.8% + HR(0°, 946nm)>99.9% + R(0°,808nm)<2% + R(0°,1064 + 1320nm)<3%
HR(0°, 500-760±6nm)>99.9%, not GVD optimized
HRp(10°, 508nm)>99.9% + Ts(10°, 254nm)=95±1%
HR(0°,515+1030nm)>99.8%
HR(0°,515nm)>99.9% + R(0°,1030nm)<1%
HR(0°,515-532nm)>99.9% (High Power)
HR(0°,515-532nm+1030-1064nm)>99.9%
HR(0°,515-545nm)>99.5% + R(0°,255-270nm)<10%
HR(0°,532nm)>99.9% (High Power)
HR(0°, 532nm)>99.9%
HRs,p(0-45°, 532nm)>99.9%
HR(0°, 532+1064nm)>99.7%
HR(0°,532nm)>99.7% + HR(0°, 1064nm)>99.9% (High Power)
HR(0°,532nm)>99.9% + R(0°,1064nm)<0.5%
HR(0°, 532nm + 1064nm)>99.9% (High Power)
HR(0°, 532+1064nm)>99.9% (substrate/HR1064-stack/HR532-stack/air)
HR(0°,532+1064nm)>99.9% + HT(0°,808nm)>90%
HR(8°,532nm)>99.5% + R(8°,266nm)<5%
HR(0-12°, 532nm)>99.9% + R(0-12°, 266nm)<10%
HR(0°,532nm)>99.8% + R(0°, 808 + 1064nm)<5%
HRr(0-10°,532nm)>99.9% + Rr(0-10°,355+1064nm)<3%
HR(0-20°,532+561+659+1064+1123+1319nm)>=99.5%
HR(0°,550-660±8nm)>99.9% + R(0°,355nm + 750-1100±5nm)<5%
HR(0-15°,561+1123nm)>99.8% + R(0°,1064nm)<50% + R(0-15°, 1319nm)<50%
HR(0°,600-670nm)>99% + PR(0°,633nm)~99.5%
Ag + protection layer, fs-opt. 600-1000nm
Ag + protection layer, fs-opt. 600-2000nm
HR(0°,630-640nm)>99.9%
HR(0°,633nm)=99.9% T(0°,633nm)>0.08%
HR(0°,650-1100nm)>99.8% + R(0°,2940nm)<5% (not GVD optimised)
HR(0°,659+1123nm)>99.8% + R(0°,1064nm)<10%
HR(0-10°,659+1319nm)>99.8% + R(0°,1064nm)<10%
HR(0°,659+1319nm)>99.8% + R(0°,1064nm)<50%
HR(0°,659+1319nm)>99.9% + R(0°,808+1064nm)<5%
HR(0°,670nm)>99.7%
HR(0°,670nm)>99.99%, T(0°,670nm)~0.001% (Low Loss)
HR(0°,700-840nm)>99.95%, GVD<20fs2
HR(0°,(708-894)±10nm)>99.99% (Low Loss), transmission not specified
HR(0°,710-890nm)>99.95% + R(0°,350-450nm)<5%
HR(0°,720-1100±8nm)>=99% + R(0°, 550-700±8nm)<5%
HR(0°,730-780nm)>99.99%, T(0°,755nm)~0.002% (Low Loss)
PR(0°,763nm)=99.900±0.015%
HR(0°,846nm)>99.9% + R(0°,423nm)<5%
HR(0°,860-980nm)>99.99%, T(0°,920nm)~0.001% (Low Loss)
HRs(0-10°,870-950nm)>99.8% + HTs(0-10°,435-475nm)>90%
HR(0°, 900-990nm)>99.9% + R(0°, 1500-1650nm)<2%
HR(0-15°, 910nm)>99.9% + R(0-15°, 457 + 808nm)<3% + R(0-15°, 1064nm)<5% + R(0-15°, 1320nm)<10%
HR(0°,910-970nm)>99.9%, (High Power)
HR(0°, 910-1340±10nm)>99.8% + R(0°, 470-620±5nm)<10%
HR(0°,914nm)>99.9% + R(0°,457+808nm)<5%
HR(0°,922nm)>99.9% + R(0°,461nm)<5%
HR(0°,930-946nm)>99.9% + R(0°,1064 + 1320nm)<2%
HR(0°,940nm)>99.8%
HR(0°,910-980nm)~99.9%, T=0.05±0.03%
HR(0-10°, 940-1070±10nm)>99.9%
HR(0°,946nm)>99.9% + R(0°,473 + 1064nm)<5% + R(0°,1320nm)<10%
HR(0°,946nm)>99.9% + R(0°,473nm)<5% + R(0°,808nm)<10% + R(0°,1064nm)<30%
HR(0°,946nm)>99.9% + R(0°,808nm)<5% + R(0°,1064nm)<10%
HR(0°,946nm)>99.9% + R(0°,885nm)<5% + R(0°,1064nm)<10%
HR(0°, 950-1100±10nm)>99.9% + R(0°, 480-500nm)<2%
HR(0°,970-1120nm)>99.9%
HR(0°, 970-1430+/-10nm)>99.9% (GD optimized for OPO-application)
HR(0°, 980-1590+/-10nm)>99.8% + R(0°, 690-930+/-8nm)<10%, GVD~ -300...0fs2 (GVD optimiert zur OPO-Anwendung)
HR(0°, 1030±40nm)>99.97% + R(0-3°, 515-543nm)>90%
HR(0°,990-1075nm)>99.99%, T(0°,1032nm)~0.001% (Low Loss)
HR(0°,990-1530±10nm)>99.7% + R(0°, 720-860±5nm)<5%
HR(0°, 995-1200nm)>99.9% + R(0°, 760-960nm)<2%
HR(0°,1000-1450nm)>99.8% + R(0°, 670-930nm)<15%(goal:<10%) + R(0°, 2400-4000nm)<20%
HR(0°,1000-1500nm)>99.6% + R(0°,490-790nm)<15%
HR(0°,1.0-1.53μm±15nm)>99.7% + R(0°,720-860±5nm)<5% + R(0°,2.1-4.0μm)<30%
HR(0°,1010-1060nm)>99.9%
HR(0°,1010-1070nm)>99.9% (High Power)
HR(0°,1010-1200nm)>99.9% + R(0°, 800-970nm)<2%
HR(0°,1010-1360nm)>99.8%, GD and GVD optimized
HR(0°, 1020-1070nm)>99.9% (High Power)
HR(0°, 1020-1070nm)>99.95% (High Power)
HR(0°,1020-1080nm)>99.9%, |GDD|<20fs2
HR(0°, 1030nm)>99.98%
HR(0°,1030nm)>99.98% (High Power)
HR(0-10°,1030nm)>99.98% + R(0-10°,630-650nm)>50% (high cw-laser power)
HR(0°, 1030nm)>99.98%(High Power) + PR(0°, 640nm)>60%
HR(0°, 1030nm)>99.9% + R(0°, 515nm)<5%
HR(0°, 1030-1064nm)>99.9%
HR(0°,1030-1064nm)>99.9% (High Power)
HR(0°,1030-1064nm)~99.9%, T=0.05±0.02%
HR(0°, 1060-1080nm)>99.5% + HR(0°, 1420-1480nm)>99.5% + R(0°, 3900-4200nm)<5%
HR(0°,1030-1100nm)>99.9% + R(0°,514-532nm)<5%
HR(0°,1030-1130nm)>99.9% + R(0°,790-980nm)<5%
HR(0°,1030-1320nm)>99.8% (not GD or GVD - optimized)
HR(0°,1030-1360nm)>99.8% + R(0°,488-532nm)<10%, not GVD opt.
HR(10°, 1030-1360nm)>99.8% + HT(10°,530-630nm)>95%
HR(0°,1040nm)>99.9%
HR(0°,1050-1070nm)>99.9%
HRr(0-45°, 1064nm)>99.8% (High Power)
HR(0°,1064nm)>99.9%
HR(0°,1064nm)>99.9% (High Power)
HR(0°, 1064nm + 1.4-2.0μm)>99.5% + R(0°, 2.3-4.0μm)<2%
HR(0°, 1064nm)>99.9% + HR(0°, 1900-2290nm)>99.0%
HR(0°, 1064nm)>99.9% + PR(0°, 2050-2200nm)=60±3%
HR(0°,1064nm)>99.992% , T(0°,1064nm)~0.001% (Low Loss)
HR(0°, 1064nm)>99.9% + R(0°, 532nm)<1%
HR(0°,1064nm)>99.9% + R(0°,532+808nm)<5%
HR(0°, 1064nm)>99.9% + R(0°, 532nm)<5%
HRs(0-6°, 1064nm)>99.95% + Rp(0-6°, 532nm)<2%
HR(0°, 1064nm)>99.98% + R(0°, 532nm)<5%
HR(0°, 1064nm)>99.9% + R(0°, 808nm)<3%
HR(0°,1064nm)>98% + R(0°,532nm)<5%
HR(0°, 1064nm)>99.9% + R(0°, 890nm)<3%
HR(0°,1064nm)>99.9% + R(0°,808nm)<2%
HR(0°,1075-1160nm)>99.99%, T(0°,1117nm)~0.001% (Low Loss)
HR(0°,1100-1250nm)>99.97%, T(0°,1170nm)~0.002% (Low Loss)
HR(0°,1100-1350nm)>99.9%, GVD<20fs2 (1120-1340nm)
HR(0°,1110-1240nm)>99.95%, T(0°,1170nm)~0.01% (Low Loss)
HR(0-15°,1120±10nm)>99.98% + R(0°,510-565nm)<5%
HR(0°,1130-1320±10nm)>99.9%
HR(0°,1150-1330±10nm)>99.9% + R(0°,510-620nm)<5%
HR(0°,1160-1245nm)>99.99%, T(0°,1203nm)~0.001% (Low Loss)
HR(0-5°,1200-1400nm)>99.8% + R(0-5°, 532 + 850-950nm)<5%
HR(0°, 1200-1400nm)>99.9% + R(0°, 1030nm)<5% + R(0°, 4000-5500nm)<5%
HR(0°, 1230-1730+/-20nm)>99.9%, GD optimized
HR(0°, 1240-1720+/-10nm)>99.9% + R(0°, 1030-1080+/-5nm)<2%, GVD~ -500...0fs2 (GVD optimized for OPO-application)
HR(0°,1250-1550±14nm)>99.9% + R(0°,720-950±8nm)<5%
HRr(0-15°,1310-1470±10nm)>99.9% + Rr(0-15°, 1064nm)<5% + Rr(0-15°, 3.0-6.0μmm)<5%, for OPO - application
HR(0°,1320-1510±10nm)>99.9%
HR(0°,1340nm)>99.9% + R(0°,808+1064nm)<5%
HR(0°,1340nm)>99.9% + R(0°,1064nm)<2%
HR(0°,1342nm)>99.9% + R(0°,671nm)<3%
HR(0°,1350-1600nm)>99.9%
HR(0-10°,1350-1700±15nm)>99.9% + R(0-10°, 1030nm)<2% + R(0-10°, 2.5-4.5μmm)<5%, for OPO - application
HR(0°, 1350-1830+/-10nm)>99.9%, GVD~0...-500fs2 (GVD optimized for OPO-application)
HR(0°, 1360-1560±15nm)>99.9% + HR(0°, 2320-2870±20nm)>99.8% + R(0°, 930-1080nm)<2%
HR(0°,1400-1700nm)>99.8%
HR(0°,1410-1800nm)>99.9% + R(0°, 1064nm)<2% + R(0°, 3-4μm)<5%
HR(0°,1410-1830nm)>99.9%
HR(0°,1450-1670±10nm)>99.8%
HR(0°, 1450-1700±15nm)~99.9% + PR(0°, 2640-3060±20nm)=99.0±0.5%
HR(0°,1500-1860nm)>99.9% + R(0°, 1030nm)<2%, GDD-R<60fs2
HR(0°,1530-1550nm)>99.9%
HR(0°,1530-1800nm)>99.9%
HR(0°,1762nm)>99.98%, T~0.002% (Low Loss)
HRr(0-15°, 1770-2020±10nm)>99.9% + Rr(0-15°, 1064nm)<5% + Rr(0-15°, 2.2-2.68μm)<5%, für OPO - Anwendung
HR(0°,1850-1950nm)>99.9% + R(0°,780-980nm)<5%
HR(0°,1900-2100nm)>99.9% + R(0°,800-1200nm)<10%
HR(0°, 1900 - 2200±20nm)>99.9%
HR(0°,2.0-2.1μm)>99.9% + R(0°,780nm)<2%
HR(0°, 2000-2240+/-20nm)>99.9%
HR(0°,2010nm)>99.8% + R(0°,2090nm)<50%
HR(0°,2010-2100nm)>99.9%
HR(0°,2010-2100nm)>99.9%, LIDT(120μs)>2MW/cm2
HR(0-10°,2050-2065nm)>99.9% (High Power)
HR(0°, 2060-2300+/-20nm)>99.9% + R(0°, 1064nm)<10%
HR(0°,2100nm)>99.9% + R(0°,808nm)<5%
HR(0°,2500-3000nm)>99.6% + HR(0°, 1064nm)>99.8% + R(0°,1550-2000nm)<5%
HR(0°,2500-3000nm)>99.6% + R(0°,1550-2000nm)<5%
HR(0°,2940nm)>99.8%
HR(0°,2940nm)>99.8% (High Power)
HR(0°,3200-3400nm)>99.7% + R(0°,1064nm)<3% + R(0°,1550-1650nm)<5%
HR(0°,4100-4300nm)>95% + R(0°,1064 + 1300-1400nm)<10%
HRs,p(0-45°, 470-490nm)>99.8%
HRr(22°,532+1064nm)>99.9%
Ag + Multilayer HRr(15-30°,532 + 1070-1080nm)>99.8% + Rr(15-30°,670nm)>80%
HR(20°,659+1123nm)>99.8% + R(20°,1064nm)<10%
HRr(22.5°,976+1030nm)>99.9% + Rr(22.5°,915nm)<2%
HRr(22.5±3°,980nm)>99.8% + Rr(22.5±3°,1030m)<2%, with angle tuning ±3°
HRp(18°,1010-1060nm)>99.9%
HRr(22.5°,1030-1064nm)>99.9% (High Power)
HRs,p(0-15°,1030-1200nm)>99.8% + Rs,p(0-15°, 800-990nm)<3%
HRr(32°, 1064nm)>99.9% (High Power)
HRs(0-70°, 1064nm)>99.95%
HRr(18°, 1064nm)>99.5% + PRr(18°, 630nm)=55±5%
HRs(12°, 1064nm)>99.9% + Rr(12°, 532+355nm)<3%
HRr(45°,200nm)>95% (fluoridic)
HRr(45°,205nm)>95% (fluoridic)
HRr(45°,211nm)>95% (fluoridic)
HRr(45°,200nm)>95%+Rr(45°,800nm)<5% (fluoridic)
HRs(45°,230-330nm)~95% + Rp(45°,380-800nm)<5%
HRr(45°,244nm)>99%
HRr(45°, 248nm)>99.5%
HRs(45°,255-265nm)>99.5% + Rp(45°,515-530nm)<5%
HRr(45°,257-262nm)>99.5%
HRr (45°, 257-292±5nm)>99.5%
HRr(45°,262nm)>99% + Rr(45°,524nm)<10%
HRs(45°,266nm)>99.5% + Rp(45°,532nm)<5%
HRs(45°,266nm)>99.5% + Rp(45°,532+1064nm)<2% + Rs(45°,532+1064nm)<10%
HRr(45°,262-266nm)>99.5%
HRr(45°,266nm)>99% + Rr(45°,355nm)<10%
HRr(45°,266nm)>99.5%
HRr(45°,266nm)>98% + Rr(45°,1000-6000nm)<5% + Tr(45°,1000-6000nm)>90%
HRr(45°,266nm)>99% + PRr(45°,532nm)>50%
HRr(45°, 266nm)>99% + Rr(45°, 532nm+1064nm)<3%
HRs(45°,342-355nm)>99.8%
HRs(45°, 340-355nm)>99.5% + Rp(45°,515-530nm)<5% + Rs(45°,1020-1060nm)<10%
HRs(45°, 343-358nm)>99.9% + Rp(45°, 515-532nm)<1% + Rs(45°, 1030-1064nm)<1%
HRp(45°,345-500nm)>99.5% + Rp(45°,690-1000nm)<5%, not GVD - optimized
HRs(45°, 355nm)>99.5% + Rp(45°,532nm)<2% + Rs(45°,1064nm)<10%
HRs(45°,350-500nm)>99.9%
HRr(45°, 355nm)>99.5%
HRr(45°, 355nm)>99.9%
HR(0°-45°, 355nm)>99%
HRr(45°, 355 + 532nm)>99%
HRr(45°,370-420±4nm)>99.9%, GVD<20fs2
HRr(45°, 425 + 850nm)>99.8%
HRs(45°,425nm)>99.9% + Rs+p(45°,825nm)<5%, GVD<20fs2
HRs+p(45°, 430nm)>99.9%
HRr(45°,475-532nm)>99.9%
HRr(45°,488nm)>99.5%
HRr(45°, 515±10nm + 1030±20nm)>99.9%
HRs(45°, 510-560nm)>99.9% + HRp(45°, 1430-1670nm)>99.8% + Rp(45°, 750-850nm)<2%
HRr(45°,514-532nm)>99.8%
HRr(45°,514-532nm)>99.9% (High Power)
HRr(45°, 515nm)>99.95% (high power for ps-pulses)
HRs,p(45°,515nm)>99.9% (high power)
HRp(45°,515-530nm)>99.5%+Rs(45°,1020-1060nm)<5%
HRr(45°, 515-532nm)>99.8% + Rr(45°, 1030-1064nm)<3%
HRs(45°, 532nm)>99.9% + HRs(45°, 1350-1750nm)>99.8% + Rs(45°, 750-850nm)<10%
HRr(45°,524nm)>99.5%
HRr(45°,530-600nm)>99.9%
HRr(45°,532nm)>99.9%
HRs,p(45°, 532nm)>99.8% + Rs,p(45°, 1064nm)<2% (high power)
HRr(45°,532+694+1064nm)>99%
HRr(45°, 532+1064nm)>99.5%
HRr(45°,532+1064nm)>99.9% (High Power)
HRs(45°, 532nm)>99.9% + HRs(45°, 1064nm)>99.9% + Rs(45°, 2100-2150nm)<5%
Ag + Multilayer HRr(45°,532nm)>99.4% + HRr(45°,1070-1080nm)>99.8% + Rr(45°,670nm)>85%
TFP(45°,532nm) Rs>99.5% Rp<3%
TFP(45°,532nm) Rs>99.9% Rp<2%
HRs(45°, 532nm)>99.9% + Rs,p(45°, 850nm)<1%
HRs(45°,532nm)>99.9% + Rp(45°,1064nm)<2%
HRr(45°, 600-680±6nm)>99.9%
HRr(45°,600-680nm)>99.5% + Rr(45°,1064nm)<2%
HRr(45°, 633nm)>99.9% + Rr(45°, 800-1000nm)<2%
HRr(45°, 635nm)>98% + Rp(45°, 532nm)<2%
HRr(45°,670nm)>99.5%
HRr(45°,685nm)>99.9%
HRr(45°, 694nm)>99.5% (High Power)
HRr(45°, 694nm)>99.8% (High Power)
HRr(45°, 694nm)>99.5% + HRr(45°, 633nm)>95%
HRs(45°,698nm)>99.9% + Rs(45°,775nm)<3%
HRr(45°,808nm)>99.9% + Rr(45°,635nm)<5%
HRr(45°,808nm)>99.9% + Rr(45°,1064nm)<3%
HRr(45°,808nm)>99.8% + Rr(45°,2000-5000nm)<10%
HRs+p(45°, 860nm)>99.9%
HRr(45°,860-1020nm)>99.9%
HRr(45°,914nm)>99.9% + Rr(45°,457nm)<5%
HRs+p(45°,940nm)>99.9%
HRr(45°, 970-1070nm)>99.9%
HRp(45°,975-1075±15nm)>99.9% (high power)
TFP(45°,980nm) Rs>99.9% Rp<2%
HRr(45°, 1000-1090nm)>99.9%
HRs(45°,10001100nm)>99.9% + Rs(45°, 1500-1600nm)<2%, /GDD-R/<40fs2
HRp(45°,1010-1060nm)>99.9%
HRp(45°, 1010-1070nm)>99.9%
HRp(45°, 1030nm)>99.95%
HRr(45°, 1030nm)>99.98% + Rr(45°,630-650nm)>50% (high cw-laser power)
HRs(45°,1030nm)>99.98% + HRp(45°,1030nm)>99.8% + Rr(45°,630-650nm)>50%
HRr(45°,1030nm)>99.9% + Rr(45°,400+700nm)<10%
TFP(45°, 1030nm) Rs>99.9% Rp<2%
HRr(45°,1030-1064nm)>99.9% (High Power)
HRr(45°, 1030-1064nm)>99.9% (high power)
TFP(45°, 1040nm) Rs>99.8% Rp<1%
TFP(45°,1047nm) Rs>99.8% Rp<2% (angle tuning ±3°)
Ag + protection layer, HRr(50-52.5°, 1064nm)>99.9%
HRr(45°, 1064nm)>99.9%
HRs(45°,1064 + 532nm)>99.9% (High Power)
HRr(45°,1064nm)>99.9% + Rr(45°,630-640nm)>90%
HRr(45°,1064nm)>99.9% + PRr(45°, 650nm)>80%
HRr(45°,1030nm)>99.9% + HTr(45°,515+808nm)>90%
HRs(45°, 1064nm)>99.9% + Rp(45°, 532nm)<1%
HRr(45°,1064nm)>99.9% + Rr(45°,532+808nm)<10%
HRr(45°,1064nm)>99.9% + Rr(45°,532nm)<10%
HRs(45°, 1064nm)>99.9% + HTp(45°, 532+808nm)>90%
HRr(45°, 1064nm)>99.9% + Rr(45°, 635 + 808nm)<5%
HRs(45°, 1064nm)>99.9% + Rr(45°, 808nm)<2%
TFP(45°, 1064nm) Rs>99.8% Rp<1%
TFP(45°, 1064nm) Rs>99.8% Rp<1% (angle adjustment ±2°)
TFP(45°,1064nm) Rs>99.8% Rp<2%
HRr(45°,1064nm)>99.8% + Rr(45°,1450-4000nm)<5%
HRp(45°, 1064nm)>99.9% + Rp(45°, 2400-3000nm)<3%
HRs(45°,1120-1280±10nm)>99.9% + Rp(45°, 1800-3000nm)<3%, GVD opimized
HRs(45°,1200-1570±10nm)>99.8% + Rp(45°, 1620-2800nm)<5%
HRr(45°,1340nm)>99.95% + Rp(45°,670nm)<2%
HRr(45°,1340nm)>99.5% + Rr(45°,808+1064nm)<5%
HRr(45°, 1342nm)>99.9%
HR(45°, 1350-1620±10nm)>99.9%, GDp~0fs2 and GVDp~-300...0fs2 optimized for OPO application
HRr(45°,1550±50nm)>99.9%
HRs+p(45°, 1500-1650nm)>99.8% + Rs+p(45°,900-990nm)<5%
HRs+p(45°, 532nm+1520-1580nm)>99.8% + Rs+p(45°, 795-825nm)<3%
HRp(45°,1535nm)>99.9% + Rp(45°,1064nm)<3% + Rs(45°,3470nm)<3%
HRs(45±2°,1600-1670nm)>99.98% + Rp(45±2°, 1535nm)<1% (angle tuning is necessary)
HRs(45°,1700-2280±10nm)>99.9% + HRp(45°, 1790-2120±10nm)>99.9% + Rs,p(45°, 750-850nm)<5%
HRs(45°,1720-2300±10nm)>99.9% + HRp(45°, 1810-2130±10nm)>99.9% + Rs,p(45°, 750-850nm)<5%
TFP(45°,2064nm) Rs>99.8% Rp<2% + Rr(45°,1940nm)<3%
TFP(45°, 2090nm) Rs>99.9% Rp<1%
HRr(45±1°,2940nm)>99% + HTr(45±1°,635-655nm)>80%
HRr(45°,515-532nm)>99.5%
TFP(56°, 266nm) Rs~98.5% Tp~95%
TFP(56°, 515nm) Rs>99.9% Rp<2%
TFP(57±2°, 532nm) Rs>99.9% Rp<2% (with angle tuning)
TFP(56°,632nm) Rs>99.8% Rp<2% (Rp<1% m.Winkeljustierung)
TFP(55°,694nm) Rs>99.8% Rp<1% (by angle tuning ±2°)
TFP(65±5°, 760-840nm) Rs>99.8% Rp<2%
TFP(65±5°, 780-860nm) Rs>99.8% Rp<2%
TFP(55+/-2°, 808nm) Rs>99.9% Rp<2%( for angle tuning +/-2°)
TFP(56°, 808nm) Rs>99.9% Rp<2%
HRs(55.6°,850-1050nm)>99.9% + HTp(55.6°, 532nm)>99.6%
HRs(55.6°,870-1100nm)>99.9% + HTp(55.6°, 532nm)>99.6%
HRs(55°,995-1000nm)>99.9% + Rp(55°,1055-1060nm)<1%
TFP(66°, 1000-1060nm) Rs>99.8% Rp<5%
TFP(65°, 1010-1060nm) Rs>99.8% Rp<5%
TFP(65°, 1010-1065nm) Rs>99.8% Rp<5%
TFP(73.6°, 1020-1060nm) Rs>99.8% Rp<5%
TFP(65°, 1020-1070nm) Rs>99.8% Rp<5%
TFP(55°,1030nm) Rs>99.95% Rp<1% (with angle tuning ±3°)
TFP(55°, 1030nm) Rs>99.9% Rp<2% (with angle tuning ±3°)
TFP(57°, 1030nm) Rs>99.8% Rp<2%
TFP(57°,1030nm) Rs>99.9% Rp<2%
TFP(54°, 1040nm) Rs>99.9% Rp<2%
TFP(55°,532nm) Rs>99.8% Rp<2%
TFP(55°,1064nm) Rs>99.9% Rp<2%
TFP(56°,532nm) Rs>99.8% Rp<2%
TFP(56°,1064nm) Rs>99.9% Rp<1%
TFP(56°,532nm) Rs>99.9% Rp<2%
TFP(57°, 1064nm) Rs>99.8% Rp<2%
TFP(56±3°,1319nm) Rs>99.9% Rp<1% (with angle tuning ±3°)
TFP(55±3°,1360-1390nm) Rs>99.9% Rp<2% (with angle adjustment ±3°)
TFP(56°,2051nm) Rs>99.8% Rp<1%
TFP(55°, 2090nm) Rs>99.9% Rp<1%(for angletuning ±3°)
PR(0°,308nm)=20%
PR(0°,308nm)=25%
PR(0°,308nm)=30%
PR(0°,397nm)=99.6±0.2%
PR(0°,405nm)=99.3±0.2%
PR(0°, 420nm)=98±0.5%
PR(0°, 425nm)=80±2% + R(0°, 850nm)<2%
PRr(0-15°, 508nm)=98.5±0.5%
PR(0°, 532nm)=53±2%
PR(13°,532nm)=97±0.5%
PR(0°, 532nm)=99.0±0.3%
PRp(10°,532nm)=99.5±0.1%
PRp(0-10°, 532nm)=96±1% + PRs(0-10°, 1064nm)=90±2%
PRp(6°,532nm)=94±1% + PRs(6°,1064nm)=94±1%
PR(0°,550-670±8nm)=85±5% + R(0°, 355nm + 720-1100nm)<5%
PR(0°, 633nm)=60±3%
PR(0°, 633nm)=75±2%
PR(0°, 633nm)=85±1%
PR(0°,633nm)=90±2%
PR(0°, 633nm)=91±1%
PR(0°, 633nm)=95±0.5%
PR(0°,633nm)=98±0.2%
PR(0°, 633nm)=99.0±0.5%
PR(0°, 633nm)=99.5±0.2%
PR(0°, 650nm)=99.8±0.05%
PR(0°, 680-730nm)=96±1% + PR(0°, 800-900nm)=90±1% + PR(0°, 950-1100nm)=96±1%
PR(0°, 694nm)=20±1%
PR(0°,780-890nm)=99±0.5%
PR(0°,795nm)=10±2%
PR(0°, 800nm±50nm)=89±1%, GVD<20fs2
PR(0°, 800nm±50nm)=90±1%, GVD<20fs2
PR(0°, 950-1460±10nm)=98.8...99.0%, GD optimized (for OPO - application)
PR(0°,922nm)=93.7±0.5% + R(0°,461nm)<5%
PR(0°,922nm)=95.7±0.5% + R(0°,461nm)<5%
PR(0°,930-946nm)=98±0.5%
PR(0°, 930- 946nm)=90.0±1.0% + R(0°, 1045-1100nm)<2%
PR(0°, 946nm)=85±1.5% + R(0°, 1064nm)<2%
PR(0°, 946nm)=95±1% + R(0°, 1064nm)<2%
PRs(20°, 920nm)=96±0.5% + Rs(20°, 1064nm)<2%
PR(0°, 946nm)=97.5±0.5% + R(0°, 1064nm)<2%
PR(0°,930-946nm)=95±1%+R(0°,1064)<2%
PR(0°,980-1110nm)=99±0.5%, GDD<20fs2
PR(0°,980-1520nm)=85±5% + R(0°,2100-4400nm)<20%
PR(0°,990-1120nm)=96±0.5%
PR(0°,1000-1100nm)=85±1%
PR(0°,1000-1100nm)=90±1%
PR(0°,1000-1100nm)=95.5±0.5%, GVD<20fs2
PR(0°,1000-1100nm)=95±1%
PR(0°,1000-1100nm)=97.5±0.5%, GDD<20fs2
PR(0°,1000-1100nm)=98±0.2%
PR(0°,1000-1100nm)=99.4±0.3%, GVD<20fs2
PR(0°,1000-1100nm)=99±0.2%
PR(0°,1000-1500nm)=97.5±0.75%
PR(0°,1000-1500±8nm)=99±0.2%
PR(0°,1020-1040nm)=87...91% + R(0°,970nm)<10%
PR(0°,1020-1040nm)=92..95% + R(0°,970nm)<10%
PR(0°,1020-1040nm)=96..98% + R(0°,970nm)<10%
PR(0°,1020-1120±8nm)=98±0.5%, GVD<20fs2
PR(0°, 1020-1120nm)=98±0.5% + R(0°, 532nm)<2%
PR(0°,1030nm)=97.3±0.3%
PR(0°, 1030nm)=84(±1%) (high cw power)
PR(0°, 1030nm)=86(±1%) (high cw power)
PR(0°, 1030nm)=88(±1%) (high cw-power)
PR(0°,1030nm)=88±1% (high cw-laser power)
PR(0°, 1030nm)=90(±1%) (high cw-power)
PR(0°, 1030nm)=92(±1%) (high cw-power)
PR(0°,1030nm)=94±0.5%
PR(0°,1030nm)=94±1% (high cw laser power)
PR(0°,1030nm)=95±1% (high cw-laser power)
PR(0°,1030nm)=96±1%
PR(0°,1030nm)=96±1% (high cw-laser power)
PR(0°,1030nm)=97±0.6% (high cw-laser power)
PR(0°,1030nm)=98±0.3%
PR(0°,1030nm)=98±0.5%, High Power
PR(0°,1030nm)=98±0.5%, High Power for cw - application
PR(0°,1030nm)=99.5±0.1%
PR(0°,1030nm)=99±0.2%
PR(0°,1030nm)=99±0.3%, high power for cw - application
PR(0°,1030-1064nm)=20±2%
PR(0°,1030-1064nm)=25(±2)%
PR(0°,1030-1064nm)=30±2%
PR(0°,1030-1064nm)=40±2%
PR(0°,1030-1064nm)=50±2%
PR(0°,1030-1064nm)=60±2%
PR(0°,1030-1064nm)=70±2%
PR(0°,1030-1064nm)=75±2%
PR(0°,1030-1064nm)=80±2%
PR(0°,1030-1064nm)=85±2%
PR(0°,1030-1064nm)=90±2%
PR(0°,1030-1064nm)=92.5±2%
PR(0°,1030-1064nm)=92±2%
PR(0°,1030-1064nm)=95±1%
PR(0°,1030-1064nm)=96.0±0.5%
PR(0°,1030-1064nm)=96.5±0.5%
PR(0°,1030-1064nm)=97±0.5%
PR(0°,1030-1064nm)=98±0.5%
PR(0°,1030-1064nm)=99.0±0.3%
PR(0°,1030-1064nm)=99.90±0.05%
PR(0°,1050-1070nm)=99.0±0.2%
PR(0°,1050-1350nm)=82±2%
PR(0°,1053nm)=86±2%
PR(0°,1064nm)=40±2%
PR(0°,1064nm)=48±2%
PR(0°,1064nm)=50±2%
PR(0°,1064nm)=55±2%
PR(0°,1064nm)=60±2%
PR(0°,1064nm)=65±2%
PR(0°,1064nm)=70±2%
PR(0°,1064nm)=75±2%
PR(0°,1064nm)=80±2%
PR(0°,1064nm)=85±1%
PR(0°,1064nm)=90±1%
PR(0°,1064nm)=92±0.75%
PR(0°,1064nm)=92±1%
PR(0°,1064nm)=94±0.75%
PR(0°,1064nm)=93±0.5%
PR(0°,1064nm)=95±0.5%
PR(0°,1064nm)=96±0.5%
PR(0°,1064nm)=98.5±0.5%
PR(0°,1064nm)=98±0.5%
PR(0°,1064nm)=99.85±0.05%, T(0°,1064nm)~0.15% (Low Loss)
PR(0°,1064nm)=99±0.2%
PR(0°, 1064nm)=75±5% + R(0°, 1100nm)>98% + R(0°,1170nm)<30%
PR(0°, 1064nm)=90±1% + R(0°, 532nm)<3%
PR(0°, 1064nm)=94±0.5% + R(0°, 532nm)<10%
PR(0°, 1064nm)=95±0.5% + R(0°, 532nm)<5%
PR(0°, 1064nm)=97±0.5% + R(0°, 532nm)<3%
PR(0°, 1064nm)=98±0.5% + R(0°, 532nm)<5%
PR(0°, 1064nm)=50±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=55±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=60±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=65±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=70±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=75±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=80±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=85±2% + R(0°, 808nm)<5%
PR(0°, 1064nm)=90±2% + R(0°, 808nm)<5%
PR(0°,1064nm)=98±0.5% + R(0°,808nm)<2%
PRr(10°,1064nm)=15±1% + Rr(10°,532nm)<2%
PR(0°,1100-1500nm)=98±0.75%
PR(0°,1178nm)=50±4%
PR(0°,1178nm)=60±4%
PR(0-12°,1178nm)=80±2%
PR(0-12°,1178nm)=96±2%
PR(0°,1220-1740±10nm)=98...98.5%, GD optimized for OPO - application
PR(0°,1225nm)=95±0.75%
PR(0°,1225nm)=99±0.3%
PR(0°, 1228nm)=99.8±0.05%
PR(0°,1228nm)=99.8±0.05%
PR(0°,1280-1520nm)=99±0.3%
PR(0°,1300-1900nm)=55±5%
PR(0°,1318nm)=90±1% (Nd:YAG laser application)
PR=97±0.5% (0°, 1330-1530nm)
PR(0°,1340nm)=98±0.5% + R(0°,1064nm)<1%
PR(0°,1342nm)=96±0.5% + R(0°,808nm)<2% + R(0°, 1064nm)<2%
PR(0°,1342nm)=98±0.5% + R(0°,808nm)<2% + R(0°, 1064nm)<2%
PR(0°,1342nm)=90±2% + R(0°,1064nm)<1%
PR(0°, 1430-1530nm)=98±0.5%
PR(0°, 1430-1530nm)=99.7±0.1%
PR(0°, 1450-1650±10nm)=98±0.75% + R(0°, 750-850±8nm)<5%
PR(0°,1450-1670±10nm)=99.3...99.4%
PR(0°,1700-2700nm)=60±5%
PR(0°,1700-2700nm)=70±5%
PR(0°,1700-2700nm)=80±5%
PR(0-15°,1760nm)=99.8±0.05% + PR(0-15°,1064nm)=92±1%
PR(0°, 2000-2300nm)=99±0.3%
PR(0°, 2000-2400nm)=97±0.5%
PR(0°,2010-2100nm)=48±2%
PR(0°,2010-2100nm)=50±2%
PR(0°,2010-2100nm)=70±2%
PR(0°,2010-2100nm)=80±1%
PR(0°,2010-2100nm)=86±1%
PR(0°,2010-2100nm)=89±1%
PR(0°, 2010-2100nm)=95±1%
PR(0°,2090nm)=70±2%
PR(0°, 2100nm)=82±1%
PR(0°, 2000-2100nm)=98±0.5%
PR(0°, 2100-2500nm)=99±0.3%
PR(0°,2600-3100nm)=98±0.7%
PR(0°,2940nm)=50±3%
PR(0°,2940nm)=70±3%
PR(0°,2940nm)=75±3%
PR(0°,2940nm)=80±2%
PR(0°,2940nm)=90±1%
PR(0°,2940nm)=92±1%
PR(0°,2940nm)=93.5±1%
PR(0°,2940nm)=95±1%
PR(0°,2940nm)=97.5±0.5%
PR(0°,2940nm)=98.5±0.5%
PR(0°,2940nm)=99.5±0.3%
PR(0°,2940nm)=99±0.5%
PRs(10-45°,355nm)=99.50±0.25%
PRs+p(30°,1064nm)=27±2%, |Rs-Rp|<5%
PRp(45°,250-280nm)=50±5%, GVD<20fs2
PRp(45°,350-470nm)=50±5%, GVD<20fs2
PRs(45°, 370-430nm)=50±5%, GVD(R+T)<20fs2
PRp(45°,400-700nm)=50±9%, GVD<20fs2
PRp(45°,490-600nm)=90±2%, /GDDp/ R+T<20fs2
PRs(45°,532nm)=30±2%
PRs(45°,532nm)=50±2%
PRs,p(45°,532nm)=50±5%, |Rs-Rp|<3%
PRs,p(45°,808nm)=50±5%, |Rs-Rp|<5%
PRs,p(45°,810nm)=50±5%, |Rs-Rp|<2%
PR(45°±0.25°,1029nm±2nm)=49.7%±0.7% mit |Rs-Rp|<5%
PRs,p(45°,1030nm)=50±5%, |Rs-Rp|<5%
PRs(45°,1030nm)=61±1% + PRp(45°, 1030nm)=56±1%, |Rs-Rp|<5%
PRs,p(45°,1064nm)=2..3%
PRs,p(45°,1064nm)=50±5%, |Rs-Rp|<5%
PRs,p(45°,1064nm)=50±6%, |Rs-Rp|<8%
PRp(45°,1064nm)=98.0±0.5%
PRs(45°,1064nm)=39±1% + PRp(45°, 1064nm)=43.5±1%, |Rs-Rp|<5%
PRs(45°,1064nm)=43±1% + PRp(45°, 1064nm)=48±1%
PRs(45°,1064nm)=52±1% + PRp(45°, 1064nm)=48±1%, |Rs-Rp|<5%
PRs(45°,1064nm)=55,5±1% + PRp(45°, 1064nm)=53,1±1%
PRs,p(45°,1550nm)=49±2%, |Rs-Rp|<2%
PRr(15°,900-1100nm)=50±2%, not GVD-optimised
PRp(45°,980-1500±10nm)=50±3%
PRp(56°,1500-1600nm)=50±1%
AR(0°,532nm)<0.5% + AR(0°,1064nm)<0.2%
AR(0°,262-266nm)<0.2%
AR(0°, 266nm)<2% + AR(0°, 355nm)<1% + AR(0°, 532nm)<0.8% + AR(0°, 1064nm)<0.3%
AR(0°,355nm)<0.25%
AR(0°,355nm)<0.25%
AR(0°,355+532nm)<0.5% + AR(0°,1064nm)<0.2%
AR(0°,400+800nm)<0.3%
AR(0°,500-1000nm)<1.5% (<0.75% avg.)
AR(0°, 515nm)<0.2%
AR(0°,515+1030nm)<0.2%
AR(0°,532nm)<0.1%
AR(0°,532nm)<0.25%
AR(0°, 532+1064nm)<0.2%
AR(0°,694nm)<0.2%
AR(0°,700-900nm)<0.25%
AR(0°,750-850nm)<0.25%
AR(0°,938+1030nm)<0.25%
AR(0°,1000-1300nm)<0.5%
AR(0°,1010-1060nm)<0.25%
AR(0°,1030nm)<0.1%
AR(0°,1030nm)<0.2%
AR(0°,1030-1064nm)<0.15%
AR(0°,1030-1064nm)<0.2%
AR(0°,1070nm)<0.15%
AR(0°, 1175-1400nm)<1% + AR(0°, 2350-2800nm)<1%
AR(0°,2050nm)<0.2%
AR(0°,2300nm)<0.25%
AR(0°,2940nm)<0.25% + R(0°,633nm)<8%
ARp(45°, 600-1000nm)<0.8%
ARr(45°,2940nm)<0.6%



低损耗激光镜片

HR(0°,266nm)>99.7%, T(0°, 266nm)~0.025±0.01% (Low Loss)
HR(0°,315nm)~99.6% (Low Loss)
HR(0°,325-360nm)>99.9%, T(0°,325-360nm)~0.004...0.015% (Low Loss)
HR(0°,330nm)>99.8%, T(0°,330nm)~0.002% (Low Loss)
HR(0°,330nm)>99.8%, T(0°,330nm)~0.01-0.015% (Low Loss)
PR(0°, 330nm)~99.95±0.02%, T(0°, 330nm)~0.03±0.02%, Low Loss
HR(0°,335-350nm)>99.8%, T(0°.342nm)~0.002% (Low Loss)
HR(0°,340-360nm)>99.9%, T(0°, 340-360nm)~0.01% (Low Loss)
HR(0°,340-360±3nm)>99.9%, T(at 355nm)~0.01-0.015% (Low Loss)
HR(0°,340-370±4nm)>99.9%, T(measurement)~0.01-0.02% (Low Loss)
HR(0°,350-365nm)>99.9% (Low Loss)
HR(0°,360nm)>99.85%, T(0°,360nm)~0.002% (Low Loss)
HR(0°,360-395nm)>99.95%, T(0°,375nm)~0.006% (Low Loss)
PR(0°, 365nm)~99.95±0.02%, T(0°, 365nm)~0.04±0.02%, low loss
HR(0°,370-395±3nm)>99.96%, T(measurement)~0.01-0.15% (Low Loss)
HR(0°,380-420nm)>99.95%, T(0°, 380-420nm)~0.006...0.015% (Low Loss)
HR(0°,380-420±4nm)>99.95%, T(measurement)~0.01-0.02% (Low Loss)
HR(0°,387nm)>99.92±0.02% (Low Loss)
HR(0°,390nm)>99.9%, T(0°,390nm)~0.002% (Low Loss)
HR(0°, 390-440m)>99.95%, T~0.007...0.03%, Low Loss
HR(0°,400-405nm)~99.975% + HR(0°,633nm)~95...99%, T(0°,400-405nm)~0.01% (Low Loss)
HR(0°,405nm)>99.98%, T(0°,405nm)~0.005%, Low Loss
HR(0°,410nm)=99.95±0.02%, T at 410nm~0.012% (Low Loss)
HR(0°,410nm)>99.9% (Low Loss)
HR(0°,420-450nm)>99.98%, T(0°, 420-450nm)~0.004...0.01% (Low Loss)
HR(0°, 430nm)>99.98%, T(0°,430nm)~0.002%, Low Loss
HR(0°, 430-490nm)>99.9%, GDD<20fs2
HR(0°,432nm)=99.95±0.02%, T~0.012% (Low Loss)
HR(0°, 440nm)>99.98%, T(0°,440nm)~0.01% (Low Loss)
HR(0°,445nm)>99.98%, T(0°,445nm)~0.01%, Low Loss
PR(0°,445nm)~99.99±0.005%, T(0°,445nm)~0.01±0.005%, Low Loss
HR(0°,455nm)>99.985% T(0°,455nm)~0.007% (Low Loss)
HR(0°,455nm)>99.985% T(0°,455nm)~0.002% (Low Loss)
HR(0°,460nm)>99.95%, T~0.02% (Low Loss)
HR(0°, 480nm)>99.98%, T(0°,480nm)~0.002%, Low Loss
HR(0°, 480nm)>99.99%, T(0°,480nm)~0.0002%, Low Loss
HR(0°,511nm)>99.97% (Low Loss)
HR(0°,520-560nm)>99.98%, T(0°,540nm)~0.003...0.005% (Low Loss)
HR(0°, 525-575+/-5nm)>99.98% (Low Loss) T~0.002%
HR(0°,532nm)>99.98% (Low Loss) T~0.01%
HR(0°,532nm)>99.99% (Low Loss) T~0.001%
HR(0°, 540nm)>99.98%, T(0°,540nm)~0.01% (Low Loss)
HR(0°,545-595nm)>99.97%, T(0°, 570nm)~0.015% (Low Loss)
HR(0°,560-680nm)>99.9% + HR(0°,570-670nm)>99.99%, T(0°,620nm)~0.001% (Low Loss)
HR(0°,570nm)>99.97±0.02%,T at 570nm~0.015% (Low Loss)
HR(0°,570-635±5nm)>99.97% T~0.001%(Low Loss)
HR(0°,585-605nm)>99.99% T(0°,595nm)~0.001% (Low Loss)
HR(0°,610-655±5nm)>99.98%, T(measurement)~0.002% (Low Loss)
HR(0°,620nm)=99.98±0.02%, T at 620nm~0.01% (Low Loss)
HR(0°,620-680nm)>99.97% T~0.01%(Low Loss)
HR(0°,620-680nm)>99.985% T(0°,650nm)~0.001% (Low Loss)
HR(0°,620-680nm)>99.99%, T(0°,650nm)~0.005...0.01% (Low Loss)
HR(0°,620-680nm)>99.99% T~0.002% (Low Loss)
HR(0°,625nm)>99.99% , T(0°,625nm)~0.001% (Low Loss)
HR(0°,630nm)=99.93±0.02%, T~0.07% (Low Loss)
PR(0°,630nm)~99.98%, T(0°,630nm)~0.01% (Low Loss)
HR(0°,633nm)=99.9% T(0°,633nm)>0.08%
HR(0°, 633nm)=99.96±0.015% + HR(0°,825+863nm)>99.99%, T(0°,633nm)~0.002% + T(0°,825+863nm)~0.001% Low Loss
HR(0°,660nm)>99.99%, T(0°,660nm)~0.001% (Low Loss)
PR(0°, 300-450nm)~99.6±0.3%, T(0°, 300-450nm)~0.3±0.2%, low loss
HR(0°,680-690nm)>99.94%, low loss, T(0°,685nm)~0.05%
HR(0°,685nm)>99.99%, low loss, T(0°,685nm)~0.002%
HR(0°,690-830nm)>99.98% (Low Loss)
HR(0°,700-800nm)>99.98% (Low Loss)
HR(0°, 727-733nm)>99.99%, T(0°, 730nm)~0.002%, low loss
HR(0°,730-780±8nm)=99.97±0.02%, T~0.01% (Low Loss)
HR(0°,740-870±5nm)>99.95% (Low Loss), T(0°,805nm)~0.002%
HR(0°,740-870nm)>99.98% (Low Loss)
HR(0°,763nm)>99.98%, T~0.015 (Low Loss)
HR(0°,777nm)>99.98% (Low Loss)
HR(0°,780nm)>99.97% (Low Loss)
HR(0°,780nm)>99.97%, T~0.02% (Low Loss)
HR(0°,780-850nm)>99.99% , T(0°, 815nm)~0.001% (Low Loss)
HR(0°,790nm)>99.97% (Low Loss)
HR(0°, 790-875±8nm)>99.97%, low Loss
HR(0°, 800nm)>99.99% ,T (0°, 800nm)~0.001% (low loss)
HR(0°,800-835nm)>99.97% T~0.01%(Low Loss)
HR(0°,830-870nm)=99.9%, T~0.1%
HR(0°, 850+/-10nm)>99.97%, T at 850nm~0.01% (Low Loss)
HR(0°,860-970nm±10nm)>99.97% T(920nm)~0.007±%(Low Loss)
HR(0°,920-950nm)>99.98% (Low Loss)
HR(0°,910-1000nm)>99.98% T ~0.007% (Low Loss)
HR(0°,920-1010nm)>99.95% T at 950nm~0.011% (Low Loss)
HR(0°,970-1120nm)>99.98% (Low Loss)
HR(0°,990-1085nm)>99.98%, |GVD(990-1085nm)|<20fs2 (Low Loss)
HR(0°, 990-1085nm)>99.99%, |GDD(0°, 990-1085nm)|<20fs2 , T(0°, 1038nm)~0.001% (Low Loss)
HR(0°,1000-1100nm)~99.9% ,T(0°,1050nm)~0.1% (low loss)
HR(0°, 1000-1110±10nm)>99.98% (Low Loss)
HR(0-20°,1020-1070nm)>99.98% (Low Loss), transmission not specified
HR(0°, 1030-1064nm)~99.994% (Low Loss) T~0.005% + PR~95...98%(0°, 600-650nm)
HR(0°,1064nm)>99.98% (Low Loss)
HR(0°,1064nm)>99.99% , T(0°,1064nm)~0.002% (Low Loss)
HRs,p(0-45°, 1064nm)>99.95%, Low Loss (transmission not specified)
HR(0°,1064nm)>99.992% , T(0°,1064nm)~0.001% (Low Loss)
HR(0°,1064nm)>99.985% + R(0°, 532nm)<2% (Low Loss)
HR(0°,1130-1190nm)>99.98% ,T (0°,1160nm)~0.01% (low loss)
HR(0°,1180-1320nm)~99.9% ,T(0°,1250nm)~0.1% (low loss)
HR(0°,1240-1450±20nm)~99.99% ,T~0.001...0.002% (low loss)
HR(0°,1240-1650)>99.96% (low loss), transmission not specified
HR(0°, 1250-1450±10nm)~99.99% (Low Loss), T~0.001....0.002%
HR(0°, 1270nm)~99.995% + PR(0°, 633nm)~95%, T(0°,1270nm)~0.0025% (low loss)
HR(0°,1280nm)>99.99% (Low Loss), T(0°,1280nm)~0.001%
HR(0°, 1300-1400±10nm)>99.98% (Low Loss), T~0.003%
HR(0°,1310nm)>99.97% (Low Loss)
HR(0°,1325nm)>99.99% (Low Loss)
HR(0°,1330-1450nm)~99.99% ,T~0.001...0.002% (low loss)
HR(0°,1360-1400nm)>99.99% (Low Loss), T~5...10ppm
HR(0°,1360-1550±10nm)>99.97% T~0.02% (Low Loss)
HR(0°,1390nm)>99.95% (low loss)
HR(0°,1392nm)>99.99% + R(0°,633nm)~95...99%, T(0°,1392nm)~0.002% (low loss)
HR(0°,1390)>99.99% (Low Loss), T at 1390nm~0.005...0.008%
HR(0°,1392nm)>99.98% (Low Loss)
HR(0°, 1392nm)>99.99%, (typical ~99.997%) T(0°, 1392nm)~0.0025% (low loss)
HR(0°,1430-1570nm)>99.99%, T(0°,1500nm)~0.001% (Low Loss)
HR(0°,1434nm)>99.99% ,T (0°,1434nm)~0.002% (low loss)
HR(0°,1450-1600nm)>99.975% (Low Loss),T at 1530nm~0,012%
HR(0°,1450-1670±20nm)~99.99% ,T~0.001...0.002% (low loss)
HR(0°,1480-1630nm)>99.98% (Low Loss), T(1510nm)~0.005%
HR(0°,1480-1630nm)>99.99% (Low Loss), T(1510nm)~0.002%
HR(0°,1500-1700nm)>99.99% (Low Loss), T(0°,1600nm)~0.0005%
HR(0°,1510nm)>99.98% (Low Loss), T at 1500nm~0.012%
HR(0°,1520-1575nm)>99.99% , T~0.0006...0.001% (Low Loss)
HR(0°,1520-1670nm)>99.97% (Low Loss), T at (1600nm)~0.005...0.007%
HR(0°,1520-1670nm)>99.99% (Low Loss), T at (1600nm)~0.001%
HR(0°,1520-1670nm)>99.99% , T(0°, 1595nm)~0.001% (Low Loss)
HR(0°,1530-1570nm)>99.97% (Low Loss),T ~0.02%
HR(0°,1530-1800nm)>99.9%
HR(0°,1570nm)>99.96% (Low Loss)
HR(0°,1570nm)>99.98% (Low Loss), T(0°,1570nm)~0.002%
HR(0°,1577+1596nm)>99.99%, T(0°,1577+1596nm)~0.002%
HR(0°, 1590nm)~99.995% + PR(0°, 633nm)~95%, T(0°,1590nm)~0.0025% (low loss)
HR(0°,1600-1700nm)>99.99% (Low Loss), T(0°,1650nm)~0.002%
HR(0°,1620-1690nm)>99.95% T~0.05% (Low Loss)
HR(0°,1600-1700nm)>99.97%, T(0°, 1650)~0.02% (Low Loss)
HR(0°,1640-1700nm)>99.97%, T~0.02% (Low Loss)
HR(0°,1650nm)>99.99% (Low Loss), T(0°,1650nm)~0.002%
HR(0°,1680-1860nm)>99.97% (Low Loss), T at (1800nm)~0.005%
HR(0°,1730-1840nm)>99.99%, T(0°,1792)~0.001...0.002% (low loss)
HR(0°,1742nm)>99.99%, T(0°,1742nm)~0.001...0.002% (low loss)
HR(0°,1760nm)>99.99% (low loss), T~0.001...0.002%
HR(0°,1870-1880nm)>99.97% (Low Loss), T at 1875nm ~0.005%
HR(0°,2022-2222nm)>99.99% ,T (0°,2122nm)~0.002% (low loss)
HR(0°,2022-2222nm)>99.99% ,T (0°,2122nm)~0.004% (low loss)
HR(0°,2050nm)>99.98% (T~0.002%)
HR(0°,2050nm)>99.98% (Low Loss), T(2050nm)~0.002%
HR(0°,2300nm)>99.98% (Low Loss), T(2300nm)~0.001...0.002%
HR(0°,2300nm)>99.99% (Low Loss), T(0°, 2300nm)~0.001%
HR(0°,2600nm)>99.9% (Low Loss), T(0°, 2600nm)~0.01%
HR(0°, 2800nm)>99.7% ,T (0°, 2800nm)~0.002% (low loss)
HR(0°,3000-3500nm)>99.7% (low loss)
HR(0°,3800-4000nm)>99.9% (low loss), T(0°, 3900nm)~0.02%
HRr(45°,633nm)>99.98% Tr~0.001% (Low Loss)
HRs(45°, 1064nm)>99.99%, T~0.002% (low loss)
PR(0°, 308nm)=99.9±0.05% , T(0°, 308nm)=0.03±0.02% (low loss)
PR(0°,370nm)=97.5...98.0%, T(0°,370nm)~2% (Low Loss)
PR(0°, 660nm)~99.95±0.02%, T(0°, 660nm)~0.04±0.02%, low loss
PR(0°, 740nm)=99.9±0.2% (low loss), T(0°,740nm)~0.08%
PR(0°, 1008nm)=99.9±0.2% (low loss), T(0°,1008nm)~0.08%
PR(0°,1112nm)=99.985±0.005%, T(0°,1112nm)~0.015% (low loss)
PRs(45°, 729nm)=99.8±0.05%, Ts(45°,729nm)~0.2% (low loss)



多功能宽带镜片

HR(0-10°,370-1480nm)>99.8%
HRs,p(45°, 400-700nm)>99.8% + HR(0°,420-800nm)>99.8% with HTr(0-45°, 950-2000nm, average)>70%
HRs,p(0-45°, 420-670nm)>99.9%
HRr(0°, 430-880nm)>99.0% + R(0°, 900-3000nm)<20% + HRr(45°, 440-740nm)>99.0% + Rr(45°, 830-3000nm)<20%
HR(0°-10°,450-1600nm)>99.5% + HR(0°-10°,1600-2150nm)>99%
HR(0-10°,460-1360nm)>99.8%
HRs,p(45°, 400-700nm)>99.8%



镀金属膜镜片

Al + protection layer, 157nm opt.
Al + SiO2-protection, R(0°, 248 + 352nm)>85%
Al + SiO2-Schutzschicht, Rr(0-45°, 266/405/810nm)>85%
Al enhanced, 220 - 280nm opt.
Al+SiO2-protection, 266 + 405nm opt.
Ag + multilayer HRr(0-45°,500-550nm)>99%, GVD<10fs2
Ag + multilayer HRr(0-45°,525-575nm)>99%, GVD<10fs2
Ag + multilayer HRr(0°,550-1250nm)>98%, |GDD(0°,550-1250nm)|<10fs2
Ag + Multilayer HR(0°,570-1000nm)>98%, |GDD|<10fs2
Ag + multilayer HR(0°,580-1040nm)>98%, |GDD|<10fs2
Ag + protection layer, fs-opt. 600-1000nm
Ag + protection layer, fs-opt. 600-2000nm
Ag + multilayer HR(0°, 650-900nm)>98.5%, GVD<10fs2
Ag + Multilayer HR(0°, 650-1050nm)>98.0%, GVD<10fs2
Ag + Multilayer HR(0°,700-900nm)>99%, GVD<10fs2
Ag + Multilayer HR(0°, 700-1000nm)>98.5%, |GDD-R(0°, 700-1000nm)|<10fs2
Ag + multilayer HR(0°,720-870nm)>99.5%, GVD optimized
Ag + enhanced 2 HR(0°, 720-1000nm)>99%, GVD(0°,720-1000nm)<30fs2
Ag + multilayer HRs+p(0-45°,730-990nm)>98%, GVD<10fs2
Au+protection layer
bare gold
Ag + Multilayer HRp(0-45°,850-1300nm)>98%, GVD<10fs2
Ag + protection layer, fs-opt. 1 - 10μm
Ag + Multilayer, HR(0°,1064nm)>99.5%
Ag +protection layer opt.2000nm HR(0°,1700-2400)>98.5%, GVD(0°,1700-2400nm)<30fs2
Ag +enhanced HR(0°, 1700-2400nm)>99%, GVD(0°,1700-2400nm)<30fs2
Ag + Multilayer HRs,p(45°,400-700nm)>98%, /GDDs,p(45°,400-700nm)/<60fs2
Ag + Multilayer HRr(45°,515nm+1030nm)>99.9% + Rr(45°, 630-660nm)>93%
Ag+multilayer HRr(45°, 532 + 1064nm)>99.5% + Rr(45°, 630-660nm)>90%
Ag + Multilayer HRp(45°,570-1000nm)>97%, |GDD|<10fs2
Ag + multilayer HRs(45°,680-940nm)>99.5%, |GDD|<10fs2
Ag + multilayer HRr(45°,700-900nm)>99%, GVD<10fs2
Ag + multilayer HRs+p(45°,700-980nm)>97%, GVD<10fs2
Ag + Multilayer HRr(45°, 700-900nm)>98%, |GDD-Rr(45°, 700-900nm)|<20fs2, Tr(45°, 800nm)=(0.03±0.02)%
Ag + Multilayer HRs,p(45°,700-1000nm)>98%, GVD<10fs2
Ag + enhanced fs-optimiert HRs(45°,710-1060nm)>99% + HRp(45°,710-1060nm)>98%, |GDD-Rs,p|(45°,710-1060nm)|<20fs2
Ag + Multilayer HRs+p(45°,750-850nm)>99.5%, GDD optimiert
Ag-enhanced: HRr(45°,798-990nm)>99% + HRr(45°,808+940+980nm)>99.5%
Ag + multilayer HRr(45°,800-1150nm)>98%, GVD<20fs2
Ag + Multilayer HRr(45°,808-1064nm)>99% + Rr(45°, 1000-2000nm)>93%
Ag + Multilayer HRr(45°,970-1110nm)>99.8%, GVD<20fs2
Ag + Multilayer HRr(45°,1030nm)>99.98% + HRr(45°,1070nm)>99.95% + Rr(45°,400-600nm)>60% + Rr(45°,600-3200nm)>90%
Ag + Multilayer, HRr(45°,1050-1500nm)>99%
Ag + multilayer HRr(45°,1050-1550nm)>98%, GVD<30fs2
Ag + multilayer, opt. HRr(45-60°,1064nm)>99.9%



激光用滤光片

HR(0°, 365 - 440nm)>99.8% + R(0°, 330 - 355nm)<5%
HR(0°,700-800nm)>99.9% + R(0°,600-660nm)<5%
HR(0°,780-900nm)>99.0% + R(0°,970-1200nm)<5%
HR(0°,810-970nm)>99.9% + R(0°,1020-1200nm)<5%
HR(0°,820-950nm)>99.8% + R(0°,1025-1150nm)<2%
HRs,p(22.5°(±3°)*,820-980nm)>99.9% + Rs,p(22.5°(±3°)*,1020-1200nm)<3%
HR(0°,820-980nm)>99.9% + R(0°,1020-1200nm)<3%
HR(0°,820-980nm)>99.5% + R(0°,1020-1200nm)<3%
HR(0°,830-970nm)>99.9% + R(0°, 500-800nm)<2%
HR(0°,830-980nm)>99.0% + R(0°,1040-1300nm)<5%
HR(0°,830-990nm)>99.9% + R(0°,1040-1200nm)<5%
HR(0°,900-990nm)>99.5% + R(0°,1030-1200nm)<3%
HR(0°,915+976nm)>99.0% + R(0°,1010-1200nm)<2%
HRr(0-15°,915-980nm)>99.9% + Rr(0-15°,1060-1090nm)<1%
HR(0°,960-990nm)>99.9% + R(0°, 915nm)<2%
HR(0°,976nm)>99.9% + R(0°,915nm)<3%
HR(0°,1010-1070nm)>99.9% + R(0°,930-955nm)<2%
HR(0°,1010-1200nm)>99.9% + R(0°, 800-970nm)<2%
HR(0°,1020-1200nm)>99.9% + HT(0°, 800-978nm)>97.5%
HR(0°,1020-1200nm)>99.9% + R(0°, 808-980nm)<2%
HR(0°,1020-1200nm)>99.95% + R(0°, 910-980nm)<2%
HR(0°,1025-1100nm)>99.9% + R(0°,808-985nm)<2%
HR(0°,1030-1100nm)>99.9% + R(0°,900-990nm)<5% [edge position varies with ±10nm]
HR(0°,1030-1200nm)>99.9% + R(0°, 820-980nm)<3%
HR(0°,1030-1200nm)>99.9% + R(0°, 820-990nm)<2%
HR(0-10°,1040-1200nm)>99.9% + R(0°, 830-1000nm)<2%
HR(0°,1064nm)>95% + R(0°,1090-1200±6nm)<2%
HR(0°,1950-2340nm)>99.9% + R(0°,1600-1880nm)<2%
HR(0°, 2050-2400nm)>99.9% + R(0°, 1640-1940nm)<2%
HR(0°, 2050-2400nm)>99.9% + R(0°, 1940nm)<2%
HR(0°,2050-2430nm)>99.9% + R(0°,1700-1960nm)<2%
HRs+p(22.5°,840-980nm)>99.8% + Rs+p(22.5°,1040-1150nm)<2%
HRs+p(22.5±5°, 820-990nm)>99.0% + Rs,p(22.5±5°, 1030-1200nm)<3%
HRs+p(22.5°, 900-990nm)>99.5% + Rs+p(22.5°,1040-1130nm)<3%
HRr(0-15°, 915-976nm)>99.9% + Rr(0-15°,1064nm)<1%
HRs+p(22.5°,976nm)>99.9% + Rs+p(22.5°,915nm)<3%
HRs+p(22.5°,1020-1200nm)>99.9% + Rs+p(22.5°, 900-970nm)<5%, with angletuning ±3°
HRr(22.5±(3°)*,1020-1200nm)>99.9% + Rr(22.5°,900-985nm)<3% *(necessary angel adjustment ±3° )
HRs+p(22.5°,1030-1200nm)>99.9% + Rs+p(22.5°,900-980nm)<1%
HRs+p(22.5°,1030-1200nm)>99.9% + Rs+p(22.5°,900-980nm)<3%, with angletuning ±3°
HRs+p(22.5°,1030-1200nm)>99.9% + Rs+p(22.5°,900-980nm)<3%
HRs+p(45°,1020-1040nm)>99.8% + Rs+p(45°,900-980nm)<5%
HRs+p(30+/-2°,1030-1200nm)>99.9% + Rs+p(30°,900-980nm)<3%
HRs+p(22.5°,1040-1200nm)>99.9% + Rs+p(22.5°,900-990nm)<5%
HRs+p(30+/-2°, 1040-1200nm)>99.9% + Rs+p(30°,900-990nm)<3%
HRs+p(22.5°,1050-1130nm)>99.9% + Rs+p(22.5°,900-990nm)<5%
HRs+p(22.5±5°,1170-1400nm)>99.9% + Rs+p(22.5°,980-1100nm)<2%, with angle tuning ±3°
HRs(45±3°,370-430nm)>99.9% + Rr(45±3°,450-800nm)<3%
HRs,p(45±3°,808+915nm)>99.5% + Rs,p(45±3°,940+980nm)<5%
HRs(45°,813nm)>99.9% + Rs(45°,780nm)<2%
HRs(45±2°,870-990nm)>99.9% + HRp(45±2°,870-975nm)>99.0% + Rp(45±2°,1020-1040nm)<2%
HRs,p(45±2°, 900-930nm)>99.5% + Rs,p(45±2°, 960-1000nm)<5% (±2° for angle tuning)
HRs,p(45±2°, 906-938nm)>99.5% + Rs,p(45±2°, 968-1000nm)<5% (±2° for angle tuning))
HRs,p(45±3°, 915nm)>99.5% + Rs,p(45±3°,940-985nm)<5%
HRp(45°, 915nm)>99.8% + Rp(45°,1060nm)<2%
HRs,p(45°, 930-940nm)>99.9% + Rs,p(45°,1030-1090nm)<3%
HRs,p(45±3°, 940nm)>99.5% + Rs,p(45±3°, 980nm)<5%
HRp(45°,950-1100nm)>99.9% + Rp(45°,600-900nm)<5%
HRr(45°,975nm)>99.9% + Rp(45°,1030nm)<2%
HRs,p(45°, 976nm)>99.9% + Rs,p(45°, 908nm)<3%
HRs(45°, 1020-1200nm)>99.9% + Rr(45°, 900-980nm)<3%
HRs,p(45°, 1020-1080nm)>99.9% + Rs,p(45°,930-940nm)<3%, |GDD-Rs,p(45°, 1030nm)|<50fs2
HRs(45±3°,1020-1200nm)>99.9% + Rs(45±3°,900-980nm)<3%, (with angle tuning ±3°)
HRs(45°, 1030-1200nm)>99.9% + Rr(45°, 900-980nm)<3%
HRs,p(45°, 1050-1100nm)>99.9% + Rs,p(45°, 900-920nm)<3%
HRr(45°, 1064nm)>99.9% + Rr(45°, 888nm)<3%
HRs(45°, 1176nm)>99.95% + Rs(45°,1064nm)<2%
HRs(45°, 2054-2065nm)>99.9% + Rs,p(45°, 1890-1940nm)<2%
HRs,p(45±3°, 2090nm)>99.8% + Rs, p(45±3°, 1908nm)<3%, with angle tuning±3°)
HRp(55±3°, 1660-1950nm)>99.9% + Rp(55±3°, 980-1620nm)<5%,angle tuning 55±3° necessary to achieve Tpmax(1620nm) with HRpmax(1640nm)






Download Catalog

catalog download
LAYERTEC catalog -
complete
(25.9 MB)

catalog download
LAYERTEC catalog -
introduction & measurement tools
(2.1 MB)

catalog download
LAYERTEC catalog -
precision optics
(2.5 MB)

catalog download
LAYERTEC catalog -
optical coatings
(3.0 MB)

catalog download
LAYERTEC catalog -
common laser types
(7.5 MB)

catalog download
LAYERTEC catalog -
femtosecond laser
(8.2 MB)

catalog download
LAYERTEC catalog -
selected special components
(4.8 MB)

catalog download
LAYERTEC catalog -
metallic coatings
(2.6 MB)


分享到 :
