公司简介
A.P.E公司成立于1992年，公司位于德国柏林，是世界上最大的飞秒测量、诊断仪器制造商。它的主要产品包括各种测量超短脉冲时域宽度的自相关仪，测量相位的SPIDER，扫描光学延迟线，声光开关，选单器件，腔倒空，倍频器等调制器件。
产品列表
OPA
| OPOfs / ps MHz OPO | fixed frequency pumpedfs / ps MHz OPO | Ti:Sa laser pumpedns kHz OPO | fixed frequency pumped
| Pulse Diagnostics
|
| Pulse Management
|
OPA
High power OPA
OPO
fs / ps MHz OPO | fixed frequency pumped
|
|
|
|
fs / ps MHz OPO | Ti:Sa laser pumped
|
Chameleon Compact OPO |
|
|
ns kHz OPO | fixed frequency pumped
|
OPO Pump Sources
Pulse Diagnostics
Autocorrelators
|
|
|
|
|
|
Peak Power Indicator
|
Spiders
|
|
|
|
Spectrometers
 |  |
Lock-in Module
HarmoniXX
 |
|
Pulse Management
Pulse Selection
|
|
|
Pulse Forming
|
Optical Delay
|
Modulator
| Analog Modulator Drivers | |||||
| Carrier frequency | 40 MHz | 80 MHz | 110 MHz | 200 MHz | |
| Modulation bandwidth | 10 MHz | 20 MHz | 27.5 MHz | 50 MHz | |
| Modulation input (600 Ω) | 0 ... 5 V | 0 ... 5 V | 0 ... 5 V | 0 ... 5 V1) | |
| RF output power | ≤1 W | ≤1 W | ≤1 W | ≤1 W2) | |
| Contrast Ratio | 1000 : 1 | 1000 : 1 | 1000 : 1 | 1000 : 1 | |
| Digital Modulator Drivers | |||||
| Carrier frequency | 40 Mhz | 80 MHz | 110 MHz | 200 MHz | |
| Rise time | < 50 ns | < 25 ns | < 20 ns | < 10 ns | |
| Modulation input (50 Ω) | TTL | TTL | TTL | TTL1) | |
| RF output power | ≤1 W | ≤1 W | ≤1 W | ≤1W2) | |
| 1) other values on request 2) higher power on request | |||||
| specifications | DFD-40 | DFD-80 |
| Frequency channel 1 (f1) | 35 ... 45 MHz | 70 ... 90 MHz |
| Frequency channel 2 (f2) | 35 ... 45 MHz | 70 ... 90 MHz |
| Resolution | 10 kHz2) | |
| Stability | 10 ppm2) | |
| Amplitude control | Independent for each channel | |
| RF output power | < 1 W @ 50 Ω each channel1) | |
| Modulation input 1/2 | Digital (on/off): TTL, 600 Ω, 100 kHz max.2) | |
| 1) higher power on request 2) other parameters on request | ||
